Description
- CAMX Hybrid - Separate BNC Outputs for Analog & HD Over Coax
- 1/2.8" 2.4 Megapixel SONY CMOS
- 30fps @ 1080P
- Min Illumination of 0.05 Lux @ F1.2, 0 Lux (IR On)
- AGC, ATW, BLC, DWDR(via OSD Menu)
- Built-in IR LEDs (100ft IR Distance)
- 2.8-12mm Vari-Focal Motorized Lens
- IP66, Water-Resistant Housing, DC12V
- Color Options: Charcoal Grey or White
IP Rating | IP66 |
Image Sensor | 1/2.8” 2.4 Megapixel SONY CMOS |
Horizontal Resolution | NTSC: 1920(H)X1080(V) |
Frame Rate | 30fps@1080P |
Minimum Illumination | 0 Lux (with IRs ON) |
Lens | 2.8-12mm Vari-Focal Motorized Lens |
S/N Ratio | MORE THAN 50dB |
IR LEDs | 850nm, 36 LEDs |
IR Distance | 100ft Depending on Scene Reflectance |
Video Standard | NTSC |
Electronic Shutter | Auto: 1/60 ~ 1/30,000s |
OSD Control | On-Screen Display Menu (Languages, Privacy Area, Color, etc.) |
Digital Noise Reduction | 2D DNR |
White Balance | Auto / Manual |
Wide Dynamic Range | DWDR |
Video Output | Separate 75 Ohm BNC Outputs for Analog & HD-CVI |
Power Supply | DC 12V, Max 4W |
Operating Temperature | -20C ~ 50C (-4C ~ 122C) |
Dimensions, Weight | 4.7” (D) x 3.48” (H), 1.9 lbs. |
