Description
This MEGApix 30x PTZ camera is NDAA-compliant and delivers crystal-clear 2.1MP/1080p resolution at real-time 30fps. The camera features 30x optical zoom, Star-Light Plus+ color in near-total darkness technology, true WDR and Smart IR+ for quality video in any lighting condition, simultaneous H.265/H.264/MJPEG codec support. The IP66- and IK10-rated vandal PTZ housing requires a wall mount, ceiling mount or flush mount, sold separately, to complete the camera’s installation.
Product Feautres :
- 2.1MP/1080p 1/3? image sensor at real-time 30fps
- Star-Light Plus+ color in near-total darkness technology
- 4.3~129mm motorized zoom PTZ lens
- 30x optical zoom
- True wide dynamic range (WDR)
- Multiple codecs (H.265, H.264, MJPEG) with simultaneous dual-stream
- Smart DNR+ 3D digital noise reduction
- True day/night with mechanical IR cut filter
- Digital Image Stabilizer (DIS)
- Programmable privacy zones
- Backlight Compensation (BLC)
- Auto white balance (AWB)
- Motion detection
- Two-way audio
- Pan 0~360° endless, 360° per second pan speed
- Vector drive technology ?? pan/tilt motion in the shortest path
- 255 preset positions
- 10 tours
- Micro SD/SDHC/SDXC class 10 card slot (card not included)
- Alarm sensor input
- Relay output
- Web server built-in
- PoE injector included
- PoE class5, DC24V and AC24V
- ONVIF conformant, profile S
- NDAA compliant
- IP66 environmental-rated dust-tight and water-resistant
- IK 10-rated impact-resistant
Files:
Specifications:
| 3D digital noise reduction | 3D DNR |
| Active Pixels | 3840 (H) x 2160 (V) |
| Advanced Lens Features | Motorized zoom, Auto focus, P-iris |
| Alarm in/out | 1 input, 1 output |
| Audio compression | G.711 |
| Audio in/out | 1 input, 1 output |
| Auto gain control | Auto |
| Bitrate Control | Multi-streaming CBR/VBR at H.264, H.265 (controllable frame rate and bandwidth) |
| Camera Control | RS485 |
| Compliance | NDAA, CF, FCC, RoHS, ONVIF |
| Day and night | Auto day/nighy, Night (B/W) |
| De-fog | Yes |
| Digital Image Stabilizer | Yes |
| Dimension | *Dimensions based on the position of the sun shield cover, 5.9" x 9.13" (150 x 232mm), 12.2” x 3.81” (310 x 97mm) |
| Event triggers | Motion Alarm, Network disconnection, Temperature critical |
| Features | Star-Light Plus |
| Focal Length | 4.3mm ~ 129mm, 4.6mm ~ 165.6mm |
| Home function | Yes, (parking action) |
| Horizontal Field of View (HFOV) | 65.1°~2.34, 58.1° ~ 1.9° |
| Housing | PTZ |
| IK rating | IK10 Rated |
| Image sensor | 2.1MP/1080p 1/3" CMOS sensor |
| IP | IPv4, IPv6 |
| IP rating | Weather Resistant (IP66) |
| IR Distance | 200" range Smart IR+, 1148" range Smart IR+ |
| LAN | RJ45 (10/100Base-T) |
| Lens Type | Vari-focal Lens |
| Materials | Metal, Polycarbonate Dome |
| Memory slot | Micro SD/SDHC/SDXC class 10 card (card not included) |
| Minimum Scene Illumination in color | 0.05 lux (color), 0.35 lux (color), 0.0 lux (B/W) |
| Mirror/flip | Yes |
| Motion Detection | Yes, 4 programmable motion zones |
| Notifications | x4, Off, x2 |
| Notifications | Email, FTP server, Alarm output activation, SD card recording |
| Operating Humidity | 10-90% (non-condensing) |
| Operating Temperature | -4°F ~ 122°F (-20°C ~ 50°C) |
| Operational Features | True D/N |
| Pan range | 360° endless |
| Pan speed | Max. 380° /sec. (preset), Max 360°/1sec |
| Pattern | 8 |
| Power Consumption | AC24V: 35W, 1485mA, DC24V: 40W, 1666mA |
| Power Requirements | 12 V DC, 24 V AC, PoE, (High power PoE injector included), PoE IEEE 802.3bt class5 |
| Preset | 256, 255 |
| Privacy Zones | 4 programmable privacy masks |
| Product Type | Cameras, Software, Product |
| Protocols | Zeroconf (AutoIP), DDNS, DHCP, DNS, FTP, HTTP, HTTPs, Bonjour, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP |
| Resolution | 2.1MP/1080p |
| Resolution | H.265: 2.1MP/1080p, 720p, VGA, D1, CIF, H.264: 2.1MP/1080p, 720p, VGA, D1, CIF, MJPEG: 1280x720, 800x600, VGA, 768x432, D1, CIF |
| Security | HTTPS (TLS), IP filtering, 802.1x, Digest authemtication (ID/PW) |
| Sharpness | Yes |
| Shutter Speed | Auto, Manual, Slow Shutter |
| Slow Shutter Speed | 8 ~ 1/30000 |
| Stream Speed | Up to 30fps at all resolutions |
| Streaming Capability | Dual-stream at different rates and resolutions |
| Test Video Output | Local video output CVBS 1.0V p-p (75O), 4:3 aspect ratio |
| Tilt range | -10~190°, 5~90° |
| Tilt speed | Max. 380° /sec. (preset), Max 360°/1sec |
| Total Pixels | 1981 (H) X 1288 (V) |
| Tour | 8, 10 |
| Video Bitrate | 100Kbps~10Mbps, multi-rate for preview and recording |
The MEGApix 2.1MP/1080p PTZ IP Camera (DWC-MPTZ230XTW) delivers exceptional clarity and performance, making it an invaluable asset for professional surveillance needs. With a robust design and advanced features, this camera is engineered for reliable installation and effortless operation, ensuring comprehensive monitoring in high-security environments.
Equipped with a powerful 4.3~129mm vari-focal lens, the camera provides 30x optical zoom capabilities, making it ideal for capturing detailed images across vast distances. Its advanced Star-Light Plus+ technology ensures vibrant color video in near-total darkness, while the true wide dynamic range (WDR) guarantees clear images in varying lighting conditions.
- 2.1MP/1080p resolution at real-time 30fps
- 30x optical zoom with motorized lens and auto-focus
- Smart IR+ technology for effective night vision
- IP66-rated housing for dust and water resistance
- IK10-rated impact resistance for added durability
- Simultaneous H.265/H.264/MJPEG codec support
- Digital Image Stabilizer (DIS) for smooth footage
- 255 preset positions and 10 programmable tours
- Remote monitoring with PoE capabilities and ONVIF compliance
- Two-way audio and motion detection features
This camera is designed for professional installers, ensuring ease of setup with wall, ceiling, or flush mount options. Protect your assets with the MEGApix 30x PTZ IP Camera, engineered for performance, durability, and reliability in any security application.
