Key Features:

• Dual Spectrum Imaging: Thermal and optical video streams are accessible via a single IP address, providing adaptable coverage for diverse scenarios.
• Thermal Fire Detection: Reliable detection for fires, smoke, and fire shield areas, with built-in alarms for rapid response.
• Temperature Monitoring: Highlights abnormal temperature changes with cold/hot spot tracking and links to alarm systems for proactive alerts.
• Smart Intrusion Prevention: Combines thermal and optical capabilities to detect line crossing, area entry/exit, and intrusion events with high precision.
• Starlight Optical Imaging: Features a high-sensitivity 1/2.8" sensor for exceptional low-light performance in the optical module.
• Smog Recognition: Optical module aids in fire alarm reconfirmation, improving accuracy in emergency scenarios.
• Picture-in-Picture Mode: Provides real-time comparison of thermal and optical views for clearer insights.
• Built-In Alarm System: Integrated audio and light alarms with red and blue warning lights enhance deterrence.
• Advanced Video Compression: Supports Ultra 265, H.265, H.264, and MJPEG formats for optimized storage and bandwidth efficiency.
• High-Resolution Recording: Optical module delivers up to 2688x1520@30fps, while the thermal module captures at 960P@30fps.
• Robust Design: Includes DC12V±25% or PoE power options, with 2 alarm inputs/outputs, 1 audio input/output, and support for up to 512GB Micro SD storage.

Compatible Mounts:

• TR-UP06-IN: Universal Pole Mounting Bracket
• TR-UC08-C: Bullet & Dome Corner Mounting Bracket
• TR-JB03-H-IN: Junction Box for Metal Turret Cameras
• TR-WM03-B-IN: Wall Mounting Bracket for 3-Inch Hemisphere
