Description
• 2.8-12mm Vari-Focal
• Smart IR, up to 30 m (98 ft) IR distance
• Lowlight Surveillance
• 3D DNR (Digital Noise Reduction)
• IK10 Vandal Resistant
• Working Environment -40°F ~ 140°F
• IR-cut filter with auto switch (ICR)
• Micro SD, up to 128 GB
• Built-in motorized lens for remote zoom
• IP66
| XIP-DZ4MPW | |
|---|---|
| Sensor | 1/3", 4.0 megapixel, progressive scan CMOS |
| Shutter | Auto/Manual, 1/6~1/8000 s |
| Lens | 2.8~12 mm@F1.6; Angle of View (H): 95° (wide) ~29° (tele) |
| Zoom/Focus | Motor drive |
| Min. Illumination | Colour: 0.02 Lux (F1.6, AGC ON) |
| 0 Lux with IR | |
| Day/Night | IR-cut filter with auto switch (ICR) |
| IR Range | Up to 30m (98 ft) IR range |
| S/N | >55 dB |
| WDR | Optical WDR (up to 120dB) |
| Video | |
| Max. Resolution | 2592 × 1520 |
| Video Compression | H.265,H.264,MJPEG |
| Capture Collect Mode | 4MP (2592×1520): Max. 20 fps; 4MP (2560×1440): Max. 25 fps |
| 3MP (2048×1520): Max. 30 fps; 1080P (1920×1080): Max. 25 fps | |
| 9:16 Corridor Mode | Supported |
| ROI | Supported |
| Video Streaming | Triple |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 4 areas |
| Smart | |
| Behavior Detection | Intrusion, crossing line, motion detection |
| Exception Detection | Audio detection |
| Intelligent Identification | Face detection |
| Statistical Analysis | People counting |
| Audio | |
| Audio Compression | G.711 |
| Two-way audio | Supported |
| Storage | |
| Edge Storage | Micro SD, up to 128 GB |
| Network | |
| Protocols | L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SIP, 802.1x |
| Compatible Integration | ONVIF, API |
| Interface | |
| Audio I/O | Audio cable |
| Input: impedance 35 kΩ; amplitude 2 V [p-p] | |
| Output: impedance 600 Ω; amplitude 2 V [p-p] | |
| Alarm I/O | 1-Jan |
| Network | 1 RJ45 10M/100M Base-TX Ethernet |
| Video Output | 1 BNC, impedance 75 Ω; amplitude 1 V [p-p] |
| Reset | 1 Reset Button |
| Power Output | DC12V Power Output With PoE |
| General | |
| Power | 12 V DC, or PoE (IEEE802.3 af) |
| Power consumption: Max.6.6 W (PoE :Max.7.2 W) | |
| Dimensions (Ø x H) | Φ148 x 111.3 mm (Ø5.8" x 4.4") |
| Weight | 0.75 kg (1.7 lb) |
| Working Environment | -40°C ~ +60°C (-40°F ~ 140°F), Humidity ≤ 95% RH(non-condensing) |
| Vandal Resistant | IK10 |
| Ingress Protection | IP66 |
Extra Information
Brand:
CAMX
