The DW MEGApix DWC-MB72Wi4TW is a workhorse 1080p outdoor bullet built for the install scenarios where you don't need 4K resolution but you do need the camera to actually work when the light disappears. Star-Light Plus pulls usable color down to 0.001 lux before the IR engages, so a parking lot at 2am still gives you license plates and clothing details instead of a black frame.
The 4mm fixed lens covers a 90° horizontal field of view, which is the sweet spot for most building perimeters, loading docks, side entrances, and small commercial lots. Smart IR throttles the IR LEDs based on subject distance so close-up faces aren't blown out into white blobs - a chronic failure mode on cheaper bullets. The IP67 housing and integrated sunshield handle weather year-round, and the 4-axis gimbal lets you tilt past flat for awkward eave or soffit mounts where most cameras can't quite get the right angle.
- Star-Light Plus color in near-darkness - usable color down to 0.001 lux before IR engages, so low-light scenes stay in color longer
- Smart IR with 100ft range - auto-adjusts intensity to subject distance, eliminating white-out on close subjects
- IVA on the camera - built-in intelligent video analytics for motion detection, line crossing, and tampering events without recorder load
- NDAA and TAA compliant - clears federal, GSA, and enterprise procurement out of the box
- 4-axis gimbal mount - extra tilt range for eaves, soffits, and awkward mounting surfaces
- PoE or 12V DC - flexible powering with low 4.5W max draw, simplifying switch sizing on multi-camera installs
Specifications
| SKU | DW-DWC-MB72Wi4TW |
|---|---|
| Brand | DW |
| Power Source | PoE (IEEE 802.3af) or 12V DC |
| Power Consumption | Max 4.5W (PoE) / Max 4.0W (12V DC) |
| Compatibility | ONVIF Profile S/G/T, DW Spectrum IPVMS |
| Certifications | NDAA-compliant, TAA-compliant, UL, CE, FCC, RoHS |
| Warranty | 5-year limited |
| Image Sensor | 1/2.8" CMOS, Star-Light Plus |
| Resolution | 1080p (1920 x 1080) at 30fps |
| Lens | 4mm fixed, F2.0 |
| Field of View | 90° horizontal |
| Minimum Illumination | 0.001 lux color, 0 lux with IR |
| IR Distance | 100ft Smart IR |
| WDR | True WDR |
| Day/Night | True Day/Night with mechanical IR cut filter |
| Noise Reduction | 3D-DNR |
| Edge Analytics | IVA (motion detection, line crossing, tampering) |
| Video Compression | H.265, H.264, MJPEG (triple codec, simultaneous) |
| Local Storage | microSD/SDHC/SDXC slot (card not included) |
| Network | 10/100 Base-T RJ-45 |
| IP Rating | IP67 |
| Mounting | Wall, ceiling, or pole (4-axis gimbal) |
| Sunshield | Integrated |
| Operating Temperature | -22°F to 122°F (-30°C to 50°C) |
| Operating Humidity | Less than 90% RH |
| Housing Material | Aluminum with polycarbonate sunshield |
