Explosionproof/Weatherproof Manual Pull Station, Single-Action DPDT, Cat 45 Key Reset, NEMA 4X
Kidde Commercial

Explosionproof/Weatherproof Manual Pull Station, Single-Action DPDT, Cat 45 Key Reset, NEMA 4X

SKU KD-MPSR1-D45WX-GE

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The MPSR1-D45WX is a single-action explosionproof manual pull station built for hazardous-location fire alarm coverage, from Class I hydrogen environments to outdoor weather exposure. Die-cast construction with plated and pre-painted surfaces resists corrosion, and the explosionproof backbox ships in the box, so there is no separate enclosure to source.

Built for the commercial fire installer

Rated for Class I Group B, C & D, Class II Groups E, F, G, and Class III hazardous locations, and NEMA 4X for outdoor use, this station covers plants, tank farms, and other locations where a standard pull station isn't rated. Cat 45 key reset keeps the station secure between activations, and the six-contact terminal block accepts 14 to 18 AWG field wiring at a 10 amp / 120 Vac switch rating. Single-action operation converts to double-action in the field with the optional MPSR-LP cover, so one base station covers both specifications.

Key features

  • Explosionproof rated: Class I Group B (hydrogen), C & D, Class II Groups E, F, G, Class III
  • NEMA 4X outdoor rated for weatherproof performance alongside hazardous-location coverage
  • Explosionproof backbox included - no separate enclosure to order
  • Cat 45 key reset keeps the station secured between tests and activations
  • Field-convertible to double-action with the optional MPSR-LP adapter cover
  • Wide operating range: -30°F to 150°F (-35°C to 66°C)

System requirements

Wires to a six-contact terminal block, 14 to 18 AWG, rated 10 amp at 120 Vac. Ships complete with the explosionproof backbox; order 276-K1 Cat 45 keys or MPSRGR10 replacement glass rods separately as needed.

Specifications

SKUKD-MPSR1-D45WX-GE
BrandKidde Commercial
Form factorSingle-action explosionproof/weatherproof manual pull station, DPDT
RatingUL/CSA Class I Group B, C & D, Class II Groups E, F, G, Class III; NEMA 4X outdoor
Dimensions3.20 x 4.75 x 3.70 in (8.13 x 12.07 x 9.40 cm), W x H x D
WiringSix-contact terminal block, 14 to 18 AWG
Switch ratings10 amp @ 120 Vac
MountingSingle gang explosionproof backbox (included)
LockCat 45 key reset
OperationSingle-action (double-action with optional MPSR-LP cover)
Operating temp-30°F to 150°F (-35°C to 66°C)
Shipping weight0.93 lb (0.42 kg)
Compatible accessoriesMPSR-LP double-action cover, MPSRGR10 replacement glass rods (10-pack), 276-K1 Cat 45 key

Documents and resources

FAQs

What hazardous locations is this pull station rated for?
Class I Group B (hydrogen), C & D, Class II Groups E, F, G, and Class III explosionproof environments. Also NEMA 4X rated for outdoor weatherproof use.
Can this be converted to double-action operation?
Yes. Order the MPSR-LP double-action cover separately to convert this single-action explosionproof station to double-action.
Does it come with a backbox?
Yes. The explosionproof backbox ships included with the station.
What key is used to reset the station?
Cat 45 key reset (model suffix -D45WX). Replacement 276-K1 Cat 45 keys are available separately.
What wire gauge does this accept?
14 to 18 AWG on the six-contact terminal block, rated 10 amp at 120 Vac.
