Genesis EG4 Series Red 4-Inch Surface Mount Back Box for Wall Notification Appliances
Kidde Commercial

Genesis EG4 Series Red 4-Inch Surface Mount Back Box for Wall Notification Appliances

SKU KD-EG4RSB

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The EG4RSB is a red 4-inch surface mount back box built for installing Kidde Genesis EG4 Series wall-mount notification appliances where flush mounting isn't an option. 16-gauge cold rolled steel construction and a durable baking enamel finish handle the demands of commercial fire alarm installations.

Built for clean surface-mount installs

Combination 1/2-inch and 3/4-inch conduit knockouts on the top, bottom, and sides give you flexible conduit routing on three faces. The rear knockout is for wire entrance only - not conduit - keeping the box profile tight against the wall. Pre-drilled and tapped #6-32 mounting holes inside line up with Genesis EG4 wall-mount horns, strobes, horn-strobes, and speakers, so the device drops right in without adapter plates or extra hardware.

Indoor rated. UL and ULC listed. 16-gauge cold rolled steel with a fire-red baking enamel finish built to last in commercial environments. Grounding provision included to meet code requirements.

Key benefits

  • Direct mount for EG4 devices: pre-drilled #6-32 holes match Genesis EG4 wall notification appliance mounting patterns
  • Flexible conduit entry: combination 1/2" and 3/4" knockouts on top, bottom, and sides
  • 16-gauge cold rolled steel: commercial-grade durability with baked enamel finish
  • Grounding provision included: meets code requirements for grounded installations
  • Indoor rated, UL/ULC listed: designed for interior commercial fire alarm applications

Specifications

SKUKD-EG4RSB
BrandKidde Commercial
Form factor4-inch surface mount back box, single-gang
Material16-gauge cold rolled steel (CRS)
FinishFire red baking enamel
MountingPre-drilled and tapped #6-32 holes
Conduit entry1/2" and 3/4" combination knockouts (top, bottom, sides)
Rear knockoutWire entrance only, not for conduit
CompatibilityGenesis EG4 Series wall-mount notification appliances (horns, strobes, horn-strobes, speakers)
EnvironmentIndoor use only
ComplianceUL listed, ULC listed
GroundingGrounding provision included

Documents and resources

FAQs

Does this box work with Genesis EG4 wall-mount devices?
Yes. The EG4RSB is designed for Genesis EG4 Series wall-mount notification appliances including horns, strobes, horn-strobes, and speakers. Pre-drilled and tapped #6-32 mounting holes align with EG4 device mounting patterns.
Can I use the rear knockout for conduit?
No. The rear knockout is for wire entrance only, not conduit. Use the top, bottom, and side knockouts for conduit runs. These are combination 1/2-inch and 3/4-inch knockouts.
Is this box rated for outdoor use?
No. The EG4RSB is indoor rated only. For outdoor Genesis notification installations, check the Kidde Commercial outdoor series accessories.
What conduit sizes does this box accept?
Combination 1/2-inch and 3/4-inch knockouts are provided on the top, bottom, and sides. This covers the most common conduit sizes used in commercial fire alarm wiring.
What is this box made of?
16-gauge cold rolled steel with a durable fire-red baking enamel finish. Built for commercial fire alarm environments.
