The Luminys LUM-CJ11B is the black-finish version of the LUM-CJ11 weatherproof aluminum junction box. Compact Ī¦124 mm x 41 mm housing, 3.0 kg (6.6 lb) load rating, IP66/IK10. Designed for Luminys mini-turret and select mini-body IP cameras deployed outdoors on dark trim.
Use it as a clean, code-friendly termination point for surface conduit runs when the mounting surface calls for a black accessory instead of white.
Compatible Camera Families
- LumiLuxSmart mini turret models (N5T-4LA2, N5T-8LA2(B), N5T-4LAV, N3T-4LAV)
- LumiDeterrent (N5T-4DA2, N5T-8DA2, N5T-8DAV, N5P-8DA2)
- LumiColor mini and standard size, LumiLightBand N3T-8BA2, IR camera N2T-4RA2
Consult the datasheet for the complete compatibility list.
Brand:
Luminys
Certifications:
IP66, IK10
Material:
Aluminum
Color:
Black
Dimensions:
Ī¦ 124.0 mm x 41.0 mm (Ī¦ 4.88 in. x 1.61 in.)
Weight:
0.4 kg (0.8 lb)
Load Bearing Capacity:
3.0 kg (6.6 lb)
Pipe Thread:
G3/4
Compatibility:
Luminys N2T, N3T, N4T, N5T, N5P mini turret and dome cameras
Form Factor:
Junction Box (Round, Mini-Turret Size)
Spec Sheet
