5MP HD-TVI IR Bullet Camera, Motorized Lens, Junction Box
SKU SP-V5B3M
- Fast shipping from four branches
- 30-day returns on unopened products
The V5B3M delivers 5MP HD-TVI video over standard coax with a motorized 2.8-12mm varifocal lens and 4x optical zoom - so you dial in the exact field of view from the DVR without climbing a ladder. At 165 feet of IR range, it covers parking lots, building perimeters, and long corridors without supplemental lighting.
Quad-format output (TVI/AHD/CVI/CVBS) means this drops into existing analog infrastructure regardless of DVR brand. The included junction box keeps wiring clean and weather-tight, and IP67 weatherproofing handles full outdoor exposure. NDAA Section 889 Part B compliance keeps the camera eligible for government and institutional contracts without a swap-out down the line.
- Motorized 2.8-12mm lens with auto focus - adjust remotely, no ladder trips
- 165ft IR range for reliable night coverage across large areas
- Quad-format output (TVI/AHD/CVI/CVBS) - works with any existing DVR
- IP67-rated for outdoor installs without an additional housing
- NDAA-compliant for government and institutional contract eligibility
- Included junction box for a cleaner, faster mount
Specifications
| SKU | SP-V5B3M |
|---|---|
| Brand | Speco |
| Operating Voltage | 12VDC (power supply not included) |
| Power Consumption | IR OFF: ≤1W | IR ON: ≤6W |
| Certifications | NDAA Section 889 Part B Compliant |
| Compatibility | AHD / TVI / CVI / CVBS (default HD-TVI) |
| Lens | 2.8-12mm Motorized with Auto Focus |
| Optical Zoom | Up to 4x |
| Resolution | 5MP (2944 x 1656) |
| Image Sensor | 1/2.5" Progressive Scan CMOS |
| Frame Rate | Up to 20 FPS |
| IR Range | 165 ft (scene dependent) |
| Minimum Illumination | Color: 0.01 lux @ F1.2 (AGC ON) | B/W: 0 lux (IR ON) |
| WDR | DWDR |
| S/N Ratio | ≥52dB (AGC OFF) |
| Smart IR | Yes |
| IP Rating | IP67 |
| Operating Temperature | -22°F to 122°F |
| Operating Humidity | 10% - 90% |
| Dimensions | 8.6"(H) x 3.2"(W) x 3.2"(H) |
| Weight | 2.46 lbs |
| Junction Box | Included |
| Warranty | 5 Years |
