AX3000 Whole Home Mesh Wi-Fi 6 Access Point with 2.5G Port and 802.3at PoE
  • Wireless technology Wi-Fi
TP-Link

AX3000 Whole Home Mesh Wi-Fi 6 Access Point with 2.5G Port and 802.3at PoE

SKU TPL-HX510-POE(1-pack) Model HX510-POE(1-pack)

  • AX3000 dual-band Wi-Fi 6 mesh access point powered over 802.3at PoE
  • One 2.5G and one Gigabit port, and both accept 802.3at PoE input
  • Ceiling and wall mounting kit included for a clean single-cable install
  • EasyMesh and 802.11k/v/r support for roaming under one network name
New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

Product highlights

  • ConnectivityAX3000 Wi-Fi 6, 160 MHz
  • Ports2.5G + Gigabit, both PoE in
  • PoE802.3at input on both ports
  • MountCeiling or wall
  • RangeEasyMesh compatible

The HX510-PoE is an AX3000 dual-band Wi-Fi 6 mesh access point that takes its power over Ethernet, so a ceiling or wall install needs one cable and no outlet. It is a clean way to add indoor coverage where the router sits at one end of the building.

Built for single-cable indoor installs

Wi-Fi 6 reaches up to 2402 Mbps on 5 GHz with 160 MHz channels and 574 Mbps on 2.4 GHz. One port runs at 2.5 Gbps and the other at Gigabit, and both accept 802.3at PoE. A ceiling and wall mounting kit is in the box. EasyMesh and 802.11k/v/r roaming let several units share one network name, and it runs in router mode or access point mode. Management is local through the web UI or the Aginet app, with TR-069, TR-369 and TAUC cloud management for service providers.

Key features

  • PoE powered: 802.3at PoE on either port, or 12V DC with the included power adapter
  • 2.5G uplink port: one 2.5 Gbps WAN/LAN port plus one Gigabit LAN port
  • Ceiling or wall mounting: mounting kit included
  • EasyMesh compatible: 802.11k/v/r roaming under one network name
  • Router or AP mode: works as the router or behind an existing gateway
  • WPA3 and guest networks: WPA3-Personal, guest network and parental controls

System requirements

An internet connection from a modem or gateway, plus 802.3at PoE from a switch or injector, or a 12V DC outlet. Set up with the Aginet app or a web browser.

Specifications

SKUTPL-HX510-POE(1-pack)
BrandTP-Link
Form factorAX3000 Wi-Fi 6 mesh access point, ceiling or wall mount
CommunicationEthernet / IP
Power inputIEEE 802.3at PoE or 12V DC (power adapter included)
Wi-Fi standardWi-Fi 6
PoE802.3at PoE+
Port speed2.5G
Port speedGigabit
Ethernet ports1 x 2.5G WAN/LAN, 1 x Gigabit LAN (both support 802.3at PoE input)
PoE featuresBoth ports accept 802.3at PoE as a powered device
Wireless standardsIEEE 802.11a/n/ac/ax (5 GHz), 802.11b/g/n/ax (2.4 GHz)
Wireless speedAX3000: up to 2402 Mbps on 5 GHz (HE160), up to 574 Mbps on 2.4 GHz (HE40)
Working modesRouter, access point
MeshEasyMesh compatible, 802.11k/v/r
SSIDs2 x 5 GHz and 2 x 2.4 GHz
Wireless securityWPA/WPA2/WPA3-Personal
VPNServer: PPTP, OpenVPN, IPSec
Communication notesIPv4/IPv6, WMM, QoS, port forwarding, parental controls, guest network, band steering; TR-069/TR-369 and TAUC for service providers
MountingCeiling or wall (mounting kit included)
Dimensions6.1 x 6.1 x 2.7 in (154 x 154 x 68.6 mm)
Operating temp32°F to 104°F (0°C to 40°C)
Operating humidity10 to 90%, non-condensing
ComplianceCE, FCC
Package contentsHX510-PoE unit, RJ45 Ethernet cable, power adapter, ceiling/wall mounting kit, quick installation guide

FAQs

Does the HX510-PoE need an Omada controller?
No. It is not an Omada-managed device. It is set up through the web UI or the Aginet app, and service providers can manage it with TR-069, TR-369 or TAUC.
How is the HX510-PoE powered?
Over 802.3at PoE on either port, or from 12V DC with the included power adapter.
Which port is the 2.5G port?
The WAN/LAN port runs at 2.5 Gbps. The second port is a Gigabit LAN port. Both support 802.3at PoE.
Can I use it as an access point behind my router?
Yes. It has a router mode and an access point mode.
Does it work with EasyMesh?
Yes. It is EasyMesh compatible and supports 802.11k/v/r for roaming under one network name.
