The DW-COVA1620T is a 16-channel cloud-optimized NVR with 20TB of pre-installed storage, built for dealers deploying DW Spectrum IPVMS. With 192Mbps of recording throughput and 8K support, it handles a full complement of high-resolution cameras without frame drops or compression artifacts.
All 16 PoE ports are integrated, so each camera run is a single cable pull with no midspan switches or injectors to rack. The included 12-month myDW subscription gives remote health monitoring, firmware management, and 16GB of cloud storage for Clip Share out of the box. NDAA-compliant for government and contract work.
- 16 integrated PoE ports - one cable per camera, no external switches needed
- 20TB pre-installed across 2 SATA bays, expandable up to 32TB
- Records up to 8K (16MP) at 192Mbps total throughput
- H.265 compression roughly halves storage use vs. H.264-only recorders
- NDAA-compliant for federal, state, and municipal contract eligibility
- 12-month myDW cloud subscription included with remote monitoring and Clip Share
Brand:
Digital Watchdog
Operating Voltage:
100-240V AC, 50/60Hz
Power Source:
AC Mains
Power Consumption:
25W (without HDDs or PoE), 200W max with full PoE load
Channels:
16
Recording Resolution:
Up to 8K (16MP)
Recording Throughput:
192Mbps
Video Compression:
H.265, H.264
Pre-installed Storage:
20TB
HDD Bays:
2x SATA
Maximum Storage:
32TB (2x 16TB)
PoE Ports:
16 (built-in)
PoE Budget:
200W
Network Interface:
1x Gigabit Ethernet (RJ-45)
Video Output:
1x HDMI (4K), 1x VGA
USB Ports:
1x USB 3.0 (front), 1x USB 2.0 (rear)
Audio I/O:
1 In / 1 Out
Alarm I/O:
4 In / 1 Out
Operating Temperature:
14Ā°F to 131Ā°F (-10Ā°C to 55Ā°C)
Operating Humidity:
10% - 93% (non-condensing)
Form Factor:
1U Rackmount
Dimensions:
15.0" x 13.0" x 1.7" (380 x 330 x 44mm)
Weight:
8.8 lbs (without HDDs)
Certifications:
NDAA-compliant, FCC Part 15, CE, UL
Compatibility:
DW Spectrum IPVMS
Cloud Services:
myDW (12-month subscription included)
Warranty:
5 Years
