MR199X14/C Heavy Duty Power Relay, DPDT 30A, 120V AC, Enclosure
Kidde Commercial

MR199X14/C Heavy Duty Power Relay, DPDT 30A, 120V AC, Enclosure

SKU KD-MR199X14/C

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The MR199X14/C gives an installer heavy-duty switching muscle for control applications that outgrow standard low-current relays - 30A DPDT contacts in a rugged steel enclosure, ready to mount and wire.

Built for the commercial fire installer

Rated for 2 HP motor loads at 30A, 300 Vac, the MR199 series handles fans, dampers, and other heavier ancillary equipment. This model runs its coil on 120 Vac, the sibling of the 24 Vdc MR199X13/C, for jobs where a line-voltage control signal is already available.

Key features

  • Heavy duty 30A DPDT contacts, rated for 2 HP motor loads
  • 120 Vac coil
  • Mounted in a sturdy steel enclosure
  • UL/ULC Listed

System requirements

Rated -22°F to 122°F (-30°C to 50°C) ambient.

Specifications

SKUKD-MR199X14/C
BrandKidde Commercial
Form factorHeavy duty DPDT power relay, steel enclosure
Contact arrangementDPDT standard
Contact rating30 Amps @ 300 Vac, 2 HP motor load
Coil power120 Vac
Temperature range-22°F to 122°F (-30°C to 50°C)
Dimensions5.31 H x 3.38 W x 3.13 D in
ComplianceUL/ULC Listed

Documents and resources

FAQs

How is this different from the MR199X13/C?
Same 30A DPDT heavy duty relay and enclosure, but with a 120 Vac coil instead of 24 Vdc.
