Pendant Ceiling Mount Bracket for N9F Fisheye, N5T Turret, N9P Multi-Sensor & P44/P45/P54/P55 PTZ Cameras
SKU LM-LUM-E02
- Fast shipping from four branches
- 30-day returns on unopened products
The Luminys LUM-E02 is a pendant ceiling mount bracket for Luminys N9F fisheye, N5T standard-size turret, N9P multi-sensor, and P44 / P45 / P54 / P55 PTZ cameras. Aluminum and PC construction with a G1-1/2 pipe thread and 4.0 kg (8.8 lb) load capacity. Enables pendant mounting with wall, pole, or corner adapters.
Key features
- Fits: N9F fisheye, N5T standard turret, N9P multi-sensor, and P44/P45/P54/P55 PTZ cameras
- Aluminum and PC construction, white finish
- Load capacity: 4.0 kg (8.8 lb)
- Pipe thread: G1-1/2
- Pairs with wall, pole, or corner adapters
- Dimensions: Φ133.6 mm x 235.5 mm (Φ5.3 in. x 9.3 in.)
Specifications
| SKU | LM-LUM-E02 |
|---|---|
| Brand | Luminys |
| Form factor | Pendant ceiling mount bracket |
| Compatible cameras | N9F fisheye, N5T standard turret, N9P multi-sensor, P44/P45/P54/P55 PTZ |
| Material | Aluminum and PC |
| Color | White |
| Load bearing capacity | 4.0 kg (8.8 lb) |
| Pipe thread | G1-1/2 |
| Dimensions | Φ133.6 mm x 235.5 mm (Φ5.3 in. x 9.3 in.) |
| Weight | 0.8 kg (1.5 lb) |
