The Luminys LUM-E02 is a pendant ceiling mount bracket for Luminys N9F fisheye, N5T standard-size turret, N9P multi-sensor, and P44 / P45 / P54 / P55 PTZ cameras. Aluminum and PC construction with a G1-1/2 pipe thread and 4.0 kg (8.8 lb) load capacity. Enables pendant mounting with wall, pole, or corner adapters.
Key features
- Fits: N9F fisheye, N5T standard turret, N9P multi-sensor, and P44/P45/P54/P55 PTZ cameras
- Aluminum and PC construction, white finish
- Load capacity: 4.0 kg (8.8 lb)
- Pipe thread: G1-1/2
- Pairs with wall, pole, or corner adapters
- Dimensions: Ī¦133.6 mm x 235.5 mm (Ī¦5.3 in. x 9.3 in.)
Brand:
Luminys
Form factor:
Pendant ceiling mount bracket
Compatible cameras:
N9F fisheye, N5T standard turret, N9P multi-sensor, P44/P45/P54/P55 PTZ
Material:
Aluminum and PC
Color:
White
Load bearing capacity:
4.0 kg (8.8 lb)
Pipe thread:
G1-1/2
Dimensions:
Ī¦133.6 mm x 235.5 mm (Ī¦5.3 in. x 9.3 in.)
Weight:
0.8 kg (1.5 lb)
Spec Sheet
