AV600 Powerline Starter Kit with 2 Adapters and 10/100 Ethernet Ports
SKU TPL-TL-PA4010 KIT Model TL-PA4010 KIT
- Fast shipping from four branches
- 30-day returns on unopened products
The TL-PA4010 KIT runs a wired network connection over a building's existing electrical wiring, so a camera recorder, TV or desktop can get Ethernet without a new cable run. The kit includes two TL-PA4010 adapters and two Ethernet cables.
Built for wired runs without new cable
Plug one adapter next to the router and the other where the wired connection is needed, then press the Pair button to link them with 128-bit AES encryption.
Key features
- Two adapters in the box: one pair covers a router-to-room link
- Powerline range: up to 300 meters (1000 feet) over existing wiring, per TP-Link
- 10/100 Ethernet port on each adapter: fits most basic wired devices
- Pair button setup: 128-bit AES encryption
- Low power draw: 2.3W typical, 0.36W standby
System requirements
Works with Windows, Mac and Linux computers. The tpPLC Utility runs on Windows and Mac OS X 10.7 or later.
Specifications
| SKU | TPL-TL-PA4010 KIT |
|---|---|
| Brand | TP-Link |
| Form factor | Wall-plug powerline adapter kit (2 adapters) |
| Communication | Ethernet / IP |
| Power consumption | 2.5W maximum, 2.3W typical, 0.36W standby |
| Port speed | Fast Ethernet |
| Ethernet ports | 1 x 10/100 Mbps per adapter |
| Standards and protocols | HomePlug AV2, IEEE 802.3, IEEE 802.3u |
| Plug type | US |
| Powerline range | Up to 1000 ft (300 m) over existing electrical wiring |
| Modulation | OFDM (PLC) |
| Encryption | 128-bit AES |
| Buttons | Pair |
| LED | Power, Powerline, Ethernet |
| Compatibility notes | Windows 2000/XP/2003/Vista, Windows 7/8/8.1/10, Mac, Linux. tpPLC Utility: Windows 10/8.1/8/7/Vista/XP and Mac OS X (10.7 or later) |
| Dimensions | 2.0 x 1.1 x 2.6 in (52 x 28.5 x 65 mm) per adapter |
| Operating temp | 32°F to 104°F (0°C to 40°C) |
| Operating humidity | 10 to 90%, non-condensing |
| Compliance | FCC, RoHS |
| Package contents | 2 x TL-PA4010, 2 x Ethernet cables, quick installation guide |
