8-Port Gigabit Ethernet PoE+ Switch IEEE 802.3at/af Power over Ethernet

No reviews yet Write a Review


8-Port Gigabit Ethernet PoE+ Switch IEEE 802.3at/af Power over Ethernet (PoE+/PoE) Compliant, 60 W, Desktop

Save installation time and money with PoE. The Intellinet 8-Port Gigabit PoE+ Switch is designed to pass both data and electrical power to a number of PoE-compatible devices via standard Cat5e or Cat6 network cables. Equipped with eight Gigabit Ethernet ports, this switch can power wireless LAN access points and bridges, VoIP phones, IP video cameras and more while delivering network speeds of up to 1000 Mbps. The Intellinet 8-Port Gigabit PoE+ Switch supports the IEEE 802.3at protocol and is designed to inject up to 30 watts of power per port. IEEE802.3af- or IEEE802.3at-compliant devices attached to the switch require no additional power, thus eliminating the time and expense of electrical rewiring and minimizing the unsightly clutter caused by power supplies and adapters in awkward places such as ceilings and walls. Any mix of PoE and non-PoE devices is supported, and thanks to its short circuit, overload and high-voltage protection function, your equipment is well-protected. The Intellinet 8-Port Gigabit PoE+ Switch features port isolation, also referred to as "Private VLAN". It isolates all ports from each other and only allows access to the uplink port. This is useful, for example, if a private VLAN is a hotel where each room or apartment has a network port for Internet access. All ports can all access the Internet, but they cannot access each other. The setup is easy: Activate the VLAN switch on the front panel of the switch, and the VLAN is enabled. That is secure port isolation with the flip of a switch!

Key Features:

  • Private VLAN
  • Power over Ethernet 802.3at
  • Provides power and data connection for up to eight PoE network devices
  • Save time and money by delivering data and power via existing network cables
  • 10/100/1000 auto-sensing ports automatically detect optimal network speeds
  • IEEE 802.3at/af-compliant RJ45 PoE/PoE+ output ports
  • Provides private VLAN (port isolation) functionality
  • Green Ethernet power-saving technology deactivates unused ports and adjusts power levels based on the cable length
  • Total power budget of 60 watts
  • Supports IEEE 802.3at and IEEE 802.3af-compliant PoE devices (wireless access points, VoIP phones, IP cameras)
  • Supports IEEE 802.3at/af detection and short circuit, overload and high-voltage protection
  • All RJ45 ports with Auto-MDIX (auto uplink) support
  • Store and forward switching architecture
  • 16 Gbps switch fabric
  • IEEE 802.3x flow control for full duplex
  • Supports up to 4096 MAC address entries
  • 1.5 Mb buffer memory
  • Fanless design ideal for silent operation
  • Desktop-size metal case
  • Port isolation / private VLAN: Switchable via button on front panel
  • Pinout RJ45 output ports (Data + Power): IEEE Alternative A, Pin 1: Rx (data receive) + Vport [+], Pin 2: Rx (data receive) + Vport [+], Pin 3: Tx (data transmit) + Vport [-], Pin 4: Unused, Pin 5: Unused, Pin 6: Tx (data transmit) + Vport [-], Pin 7: Unused, Pin 8: Unused
  • Certifications: FCC Class B, CE, RoHS
  • LEDs: PoE, Power, Link/activity
  • Power-Input: 100 – 240 V AC, 50 – 60 Hz
  • Power consumption: 67.3 watts (maximum)

Package Contents:

  • 8-Port Gigabit PoE+ Switch
  • Power adapter
  • Power cable
  • User manual

Extra Information

IC Intracom USA, Inc.
