The DWC-XSWA08Bi is a 4K panoramic camera built for wide-open coverage from a single mounting point. The 2.3mm ultra-wide lens delivers a 180-degree field of view, replacing two or three conventional fixed cameras in hallways, retail floors, and open office layouts. AI deep learning analytics run on-camera for people detection, line crossing, and intrusion without loading the NVR.
Star-Light Plus technology and a 1/1.8" image sensor keep the picture usable in near-total darkness, backed by 100ft of Smart IR that adjusts intensity to avoid blowout at close range. The camera runs on standard PoE (802.3af), mounts on a standard wall bracket or junction box, and is NDAA-compliant for government sites. Triple codec support (H.265, H.264, MJPEG) gives flexibility across VMS platforms.
- 180 panoramic FOV from a single camera - reduces camera count and cable runs
- AI deep learning analytics on-board (people detection, line crossing, intrusion, face detection)
- Star-Light Plus with 1/1.8" sensor for low-light performance down to 0.03 lux (color)
- 100ft Smart IR with auto-intensity adjustment to prevent close-range washout
- PoE powered (802.3af) - single cable for power and data
- NDAA-compliant, ONVIF Profile S/T conformant
Specifications
| SKU | DW-DWC-XSWA08Bi |
|---|---|
| Brand | DW |
| Operating Voltage | 12V DC / PoE (802.3af) |
| Power Source | PoE (802.3af) or 12V DC |
| Power Consumption | Max 12.95W |
| Image Sensor | 1/1.8" 8MP Progressive Scan CMOS |
| Resolution | 8MP (3840 x 2160) |
| Lens | 2.3mm ultra-wide fixed |
| Field of View | 180° (H) x 96° (V) |
| Minimum Illumination | 0.03 lux (color), 0 lux (IR on) |
| IR Range | 100ft (30m) Smart IR |
| Video Compression | H.265, H.264, MJPEG |
| Frame Rate | Up to 30fps at 8MP |
| WDR | True WDR (120dB) |
| AI Analytics | People detection, line crossing, intrusion, face detection, scene change |
| Audio | Built-in microphone, 1 In / 1 Out |
| Alarm I/O | 1 In / 1 Out |
| Storage | MicroSD/SDHC/SDXC (up to 512GB) |
| Network Interface | 1x RJ-45 10/100 Ethernet |
| Compatibility | ONVIF Profile S/T, DW Spectrum IPVMS |
| Operating Temperature | -22°F to 140°F (-30°C to 60°C) |
| Operating Humidity | 0% - 95% (non-condensing) |
| IP Rating | IP67 |
| Vandal Rating | IK10 |
| Mounting | Wall mount (bracket included) |
| Dimensions | 10.6" x 4.0" x 4.7" (270 x 102 x 119mm) |
| Weight | 2.2 lbs (1.0 kg) |
| Certifications | NDAA-compliant, FCC, CE, UL |
