The 438D-10N5-R puts a loud, unmistakable alloy-steel gong on the wall or ceiling for jobs where a traditional vibrating bell is the right call over an electronic horn - retrofits, older buildings, or specs that call for it by name.
Built for the commercial fire installer
The 10-inch gong reaches 88 dBA at 10 feet, loud enough for larger or noisier spaces where the smaller 6-inch and 8-inch bells in the line fall short. Heavy-duty cast underdome construction and a rugged, compact vibrating mechanism keep power draw low (0.034A at 120 Vac) while running continuously. The included mounting plate fits any standard single-gang opening, and the optional 449 weatherproof back box extends it to outdoor and wet locations.
Key features
- 10-inch alloy-steel gong, 88 dBA at 10 ft
- Vibrating, diode-polarized operation on 120 Vac
- Low power draw: 0.034A
- Indoor or outdoor with the optional 449 weatherproof back box
- Wall or ceiling mount, fits standard single-gang, 3-1/2", 4" octagon, or 4" square boxes
System requirements
Mounts to any standard single-gang electrical opening using the included mounting plate. For outdoor or wet locations, order the 449 weatherproof surface mount box (gray, with gasket) separately.
Is this rated for outdoor use?
Can this be wall or ceiling mounted?
Is a gray finish available instead of red?
Spec Sheet
