25W Audio Evacuation Expansion Amplifier Panel for ANS Fire Alarm Systems - Gray
Kidde Commercial

25W Audio Evacuation Expansion Amplifier Panel for ANS Fire Alarm Systems - Gray

SKU KD-ANS25XG

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The ANS25XG adds 25 watts of voice evacuation power to existing Kidde ANS series fire alarm systems without requiring a second main panel. Mount it in the same UL Listed enclosure, connect to the main panel's audio bus, and extend coverage to additional speaker circuits - getting full NFPA 72 voice evacuation compliance across larger buildings or harder-to-reach zones.

Built for the commercial fire alarm installer

Designed to work with the ANS25, ANS50, and ANS100 main audio notification panels, this expansion amplifier supports both 25V and 70.7V speaker circuits, field selectable to match whatever's already on the wall. Modules can be ganged together for up to 2,000 watts total system audio power, so coverage scales with the building without replacing the core system. Integrated power supply and battery charger mean the expansion panel carries its own power resiliency.

Key features

  • 25W amplifier expands ANS system output without a second main panel
  • Field selectable 25V or 70.7V speaker output to match existing circuit voltage
  • Stackable architecture: gang multiple modules for up to 2,000W total system power
  • Integrated power supply and battery charger for standalone power resiliency
  • NFPA 72 compliant voice evacuation for UL Listed fire alarm applications
  • Gray cabinet for low-visibility commercial installations (also available in red as ANS25XR)

System requirements

Requires a Kidde ANS series main audio notification panel (ANS25MDR2, ANS50MDR2, or ANS100MDR2) as the system controller. The expansion panel connects to the main panel's audio bus and receives signal, tone, and paging commands from the host system.

Specifications

SKUKD-ANS25XG
BrandKidde Commercial
Form factorAudio evacuation expansion panel, gray cabinet
Power output25W amplifier
Speaker outputField selectable 25V or 70.7V RMS
Power input120 VAC with integrated power supply and battery charger
System scalabilityUp to 2,000W total when ganged with additional modules
ComplianceNFPA 72 Emergency Voice Alarm, UL Listed
CompatibilityKidde ANS25MDR2, ANS50MDR2, ANS100MDR2 main panels
ColorGray (also available in red as ANS25XR)

Documents and resources

FAQs

What main panels does the ANS25XG expansion panel work with?
The ANS25XG is compatible with the Kidde ANS25MDR2, ANS50MDR2, and ANS100MDR2 main audio notification panels. It connects to the main panel's audio bus and receives signal, tone, and paging commands from the host system.
How much total audio power can I get by stacking expansion modules?
ANS expansion modules can be ganged together to provide up to 2,000 watts total audio power across the system. Each ANS25XG adds 25W of output.
Does the ANS25XG support both 25V and 70V speaker circuits?
Yes. The ANS25XG is field selectable for either 25V or 70.7V RMS speaker output. Set it to match the existing circuit voltage already deployed in the building.
Does this expansion panel meet NFPA 72 voice evacuation requirements?
Yes. The ANS series meets NFPA 72 Emergency Voice Alarm requirements for UL Listed fire alarm applications.
What is the difference between the ANS25XG and ANS25XR?
Color only. The ANS25XG is gray and the ANS25XR is red. Both are 25W expansion panels with identical electrical specifications. Choose based on your installation's aesthetic requirements.
