Genesis Explosionproof Xenon Strobe for Class I Division 1 & 2 Hazardous Locations, 125 cd Ceiling / 60 cd Wall, UL 1971 ADA Compliant
Kidde Commercial

Genesis Explosionproof Xenon Strobe for Class I Division 1 & 2 Hazardous Locations, 125 cd Ceiling / 60 cd Wall, UL 1971 ADA Compliant

SKU KD-116DEGEX-FJ

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The 116DEGEX-FJ drops into Class I Division 1 and 2 hazardous locations where standard notification appliances can't go. This Genesis explosionproof xenon strobe delivers 125 cd ceiling or 60 cd wall output per UL 1971, with negligible in-rush current that won't trip supervised circuits on activation.

Built for hazardous environment installs

Factory-sealed construction means no external seals to manage on site. The modular design threads onto wall, ceiling, or pendant mounting modules (sold separately) for flexible positioning in refineries, grain mills, laboratories, and other classified areas. Epoxy powder coat resists corrosion in harsh industrial environments. cUL listed to CAN/ULC-S526-07 and UL 1638 for indoor and outdoor use with dome guard installed.

Key features

  • Explosionproof rated: UL Listed for Class I Div 1 & 2 (Groups A-D), Class II Div 1 & 2 (Groups E-G), and Class III hazardous locations
  • 125 cd ceiling / 60 cd wall per UL 1971 - ADA compliant for hearing-impaired signaling in non-sleeping areas
  • Factory sealed: no external seals required at the point of installation
  • Three mounting options: wall bracket (116EX-B), ceiling/wall module (116EX-C), or pendant module (116EX-P) with 3/4" NPT conduit entries
  • Synchronized flash with external module - compatible with VM, VS, and FX Series FACPs
  • NEMA Type 3R and 4X enclosure, cUL listed for indoor and outdoor applications

System compatibility

Synchronization requires a separately installed module. Compatible FACPs include VM and VS Series life safety systems and FX Series fire alarm control panels. Compatible sync modules: GSA-CC1S, GSA-MCC1S, SIGA-CC2A, GSA-MCC2A, EG1M-RM. Compatible power supplies: MIRBPS6A, MIRBPS10A, APS6A, APS10A.

Specifications

SKUKD-116DEGEX-FJ
BrandKidde Commercial
Form factorExplosionproof strobe, xenon flash
MountingPendant, ceiling, or wall (mounting modules sold separately)
Light output125 cd ceiling, 60 cd wall (per UL 1971)
Flash rate1 Hz (65 flashes per minute)
Voltage range16-33 Vdc, 16-33 VFWR
Operating current0.505A @ 24 Vdc (regulated), 0.683A @ 24 VFWR
Operating temp-40°F to 150°F (-40°C to 66°C)
Hazardous location classificationsClass I Div 1 Groups C & D, Div 2 Groups A-D; Class II Div 1 Groups E, F & G, Div 2 Groups F & G; Class III Div 1 & 2
NEMA ratingType 3R, Type 4X, cUL listed
Agency listingscUL
ADA complianceUL 1971 listed signaling appliance for the hearing impaired, indoor non-sleeping areas
Lens colorClear
Strobe typeXenon - clear/nominal white flash
FinishGray powder coat epoxy
Conduit entry3/4" NPT
SynchronizationExternal module required (GSA-CC1S, GSA-MCC1S, SIGA-CC2A, GSA-MCC2A, EG1M-RM)
Compatible FACPsVM and VS Series life safety systems, FX Series fire alarm control panels
Compatible power suppliesMIRBPS6A, MIRBPS10A, APS6A, APS10A

Documents and resources

FAQs

What hazardous location classifications does this strobe cover?
UL Listed for Class I Div 1 (Groups C & D), Div 2 (Groups A-D); Class II Div 1 (Groups E-G), Div 2 (Groups F & G); Class III Div 1 & 2. Covers refineries, grain mills, labs, and other classified environments.
Does this strobe require field sealing at installation?
No. The 116DEGEX-FJ is factory sealed. No external seals are required at the point of installation, which saves time on the job in hazardous locations.
What mounting options are available?
Three modules (sold separately): wall bracket elbow (116EX-B) with 3" hub, ceiling/wall module (116EX-C) with 3/4" conduit entries, and pendant module (116EX-P) with 3/4" NPT entry. The strobe threads onto any of them.
What fire alarm panels and sync modules is this compatible with?
Sync requires external module. FACPs: VM, VS Series, FX Series panels. Modules: GSA-CC1S, GSA-MCC1S, SIGA-CC2A, GSA-MCC2A, EG1M-RM. Power supplies: MIRBPS6A, MIRBPS10A, APS6A, APS10A.
Is this strobe ADA compliant?
Yes. UL 1971 listed as a signaling appliance for the hearing impaired in indoor, non-sleeping areas. Delivers 125 cd ceiling or 60 cd wall output, meeting or exceeding UL 1971 requirements when pendant, wall, or ceiling mounted.
Can this be used outdoors?
Yes. cUL listed to ULC-S526-07 and UL 1638 for indoor and outdoor use with dome guard (116-GRD) installed. NEMA 3R and 4X rated. ADA/UL 1971 visual signaling applies to indoor non-sleeping areas only.
