The 116DEXMSTC-FJ is an explosionproof strobe for hazardous location fire alarm notification. Diode polarized with a clear lens, it flashes at 65 fpm and operates across 16 to 33 VDC.
Built for the commercial fire installer
Classified areas rule out standard notification appliances entirely: refineries, chemical process areas, paint booths, fuel handling, and grain facilities need an appliance whose enclosure will contain an internal ignition rather than one that simply resists the environment. This is that appliance, in a housing weighing 12.4 pounds.
Diode polarization means the device draws only on correct polarity, so the notification circuit stays supervised. The wide 16 to 33 VDC range accommodates voltage drop on the long runs these installations usually involve.
Key features
- Explosionproof housing for classified hazardous locations
- Diode polarized so the notification circuit remains supervised
- Clear lens at 65 flashes per minute
- 16 to 33 VDC operating range, tolerating voltage drop on long circuit runs
System requirements
The mounting bracket is ordered separately and must be selected for the installation. Confirm the area classification against the appliance rating before specifying, and verify total notification circuit load and end-of-line voltage against the panel or booster capacity.
