Double-Action Manual Release Station for Fire Suppression Systems
Kidde Commercial

Double-Action Manual Release Station for Fire Suppression Systems

SKU KD-278A-REL

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The Kidde 278A-REL is a double-action manual release station built for fire suppression systems - clean agent, CO2, wet chemical, and similar releasing applications. Double-action operation (lift the cover door, then pull the handle) prevents accidental activation in high-traffic areas while keeping the release mechanism immediately accessible during an emergency.

Built for the commercial installer

Red Lexan 940 housing with white raised "MANUAL RELEASE" and "LIFT THEN PULL HANDLE" lettering meets AHJ visibility requirements out of the box. UL listed (UL38, S218) and FM approved. Pulling the handle breaks a glass rod and latches the toggle switch in the alarm position - no momentary contacts, no false resets. The station resets with the supplied 276-K1 key, restoring the toggle switch and accepting a replacement glass rod (276-GLR, sold separately).

Key benefits

  • Double-action prevents accidental trips: the upper cover door must be lifted before the handle is accessible
  • Latch-action toggle switch: holds the release signal until manually reset with the supplied key
  • Surface or semi-flush mounting: surface-mount on a 276B-RSB backbox or semi-flush in a standard 4" square box with single gang plaster cover
  • Break glass operation: provides visible tamper evidence and confirms activation
  • UL listed (UL38) and FM approved: meets code requirements for manual release stations in suppression system installations

Mounting options

For semi-flush installations, use a standard North American 4" square backbox with a single gang plaster cover - minimum depth of 2-1/4" (57mm). For surface mount, pair with the Kidde 276B-RSB red surface backbox (sold separately).

Specifications

SKUKD-278A-REL
BrandKidde Commercial
Form factorDouble-action manual release station
OperationBreak glass rod, lift door then pull handle, latch action until key reset
HousingRed Lexan 940, white raised letters
Contact rating (single pole)3.0A @ 30 VAC / 1.0A @ 28 VDC, resistive load
Contact rating (double pole)1.5A @ 30 VAC / 1.0A @ 28 VDC, resistive load
Reset methodKey operated (276-K1 key supplied)
MountingSurface (276B-RSB backbox) or semi-flush (4" square box, min depth 2-1/4")
Dimensions3-9/16" x 5-3/16" x 1-13/32" (81 x 132 x 36mm)
Weight1 lb (0.4 kg)
Labeling"MANUAL RELEASE" / "LIFT THEN PULL HANDLE"
ComplianceUL38 (S218), FM

Documents and resources

FAQs

What is the difference between a manual release station and a fire alarm pull station?
Same housing and double-action operation. Release stations are labeled "MANUAL RELEASE" for suppression systems; pull stations are labeled "PULL FOR FIRE" for fire alarm circuits.
What mounting options are available for the 278A-REL?
Surface mount on a 276B-RSB backbox, or semi-flush in a standard 4" square box with single gang plaster cover (min depth 2-1/4").
What key resets this station?
The 276-K1 station reset key ships with each unit. After reset, install a replacement glass rod (276-GLR, sold separately) to return to service.
Can I get replacement break glass rods?
Yes. Order Kidde 276-GLR for replacement glass rods.
Is the 278A-REL UL listed?
Yes. UL listed under UL38 (S218) and FM approved for manual release station use in suppression system installations.
