Genesis LED EG4 Series Wall Mount Fire Alarm Speaker, White, No Marking
Kidde Commercial

Genesis LED EG4 Series Wall Mount Fire Alarm Speaker, White, No Marking

SKU KD-EG4SWN

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The Kidde Genesis LED EG4SWN is a wall-mount fire alarm speaker designed for commercial voice evacuation and notification circuits. Low-profile at just 1.62 inches off the wall, it mounts flush on standard electrical boxes and connects directly to the FACP speaker circuit with 12-18 AWG in-out screw terminals. Room side wiring plate (GP10) included for fast installation.

Built for the commercial installer

The EG4 Series design fits 1-gang, 2-gang, 3.5-inch octagon, and 4-inch square electrical boxes with no special hardware. Quick-swap covers let you change markings in the field without pulling the device off the wall - swap from unmarked to FIRE or ALERT without rewiring. No visible mounting screws on the finished install. UL listed (S298, S5389) and FCC compliant.

Key features

  • Low-profile wall mount: only 1.62" protrusion from the mounting surface for a clean, unobtrusive installation
  • Fits standard electrical boxes: 1-gang, 2-gang, 3.5-inch octagon, and 4-inch square (minimum 1-1/2" deep)
  • Quick-swap covers: change markings without removing or rewiring the device
  • Room side wiring plate included: GP10 wiring plate ships with the device for room-side wiring access
  • Under-cover diagnostic test points: verify the notification appliance circuit without pulling the device
  • Wide voltage range: 16 to 33 VDC or 16 to 33 VFWR for flexible integration with existing panels

System requirements

Connects to any Kidde or compatible fire alarm control panel speaker circuit. Synchronization supported through Kidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, and Intelligent and Conventional Control Panels. Maximum 20 ohms between any two synchronized devices on the circuit.

Specifications

SKUKD-EG4SWN
BrandKidde Commercial
Form factorWall mount fire alarm speaker
Operating voltage16 to 33 VDC, 16 to 33 VFWR
Wire size12 to 18 AWG (0.75 to 2.50 mm²)
Dimensions4.95 x 5.78 x 1.62 in (12.57 x 14.68 x 4.11 cm)
Compatible electrical boxes1-gang, 2-gang, 3.5-inch octagon, 4-inch square (min 1-1/2" deep)
Housing colorWhite
Housing markingNone
Synchronization20Ω max between any two devices
Synchronization sourcesKidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, Intelligent and Conventional Control Panels
Operating temp32 to 122°F (0 to 50°C)
Operating humidity0 to 93% noncondensing
Storage temp-40 to 158°F (-40 to 70°C)
Trim plate optionsEG4TW (white), EG4TR (red) - sold separately
ComplianceUL listed (S298, S5389), FCC
Included accessoriesGP10 Room Side Wiring Plate

Documents and resources

FAQs

What electrical boxes does the EG4SWN fit?
Fits 1-gang, 2-gang, 3.5-inch octagon, and 4-inch square electrical boxes. Boxes must be at least 1-1/2 inches (3.81 cm) deep.
Can I change the marking without rewiring?
Yes. The EG4 Series uses quick-swap covers. Remove the existing cover and snap on a FIRE or ALERT marked cover without disturbing wiring or removing the device from the wall.
What panels is this speaker compatible with?
The EG4SWN connects to any Kidde or compatible FACP speaker circuit. Synchronization is supported through Kidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, and both Intelligent and Conventional Control Panels.
Does this include a room side wiring plate?
Yes. The GP10 Room Side Wiring Plate is included. Optional EG4T trim plates (EG4TW white, EG4TR red) are available separately.
How far does the speaker protrude from the wall?
The EG4 appliance protrudes just 1.62 inches (4.11 cm) from the mounting surface. With the optional EG4T trim plate, the trim plate adds 0.3 inches.
