P5-S 4MP 45x Lumisearch Ptz With Ir
SKU LM-P55-4SA45
- Fast shipping from four branches
- 30-day returns on unopened products
The Luminys P55-4SA45 puts 45x optical zoom and AI-driven target tracking in a hardened PTZ housing rated for -40 to 158 degrees F. Whether it's a wide parking lot, a loading dock, or a perimeter fence line, this camera covers the ground between "something moved" and "here's who it was." NDAA compliant, PoE+ powered, ONVIF-native.
Built for demanding commercial installations
A 1/2.8-inch 4MP Progressive CMOS sensor with 45x optical zoom (4.0 to 177.8 mm) delivers clear identification at distances where other PTZs are still guessing. Four IR LEDs push IR coverage to 492 feet. LumiPolarPro keeps the unit running at -40 degrees F; LumiDesertPro handles the 158 degrees F end. IP67 weather sealing and IK10 impact resistance protect the housing. Wall mount bracket included.
Key features
- 45x optical zoom: 4.0 to 177.8 mm focal range for confident identification at long range
- LumiSearch AI tracking: locate a person across any LumiSearch-enabled camera or NVR using body shape and gait -- no facial recognition, no pre-enrollment required
- LumiTracking: automated PTZ target-following using AI-predicted direction and speed -- camera stays on the subject without operator input
- LumiFocus: keeps subjects sharp through the full zoom range without manual refocus
- 492-ft IR range from four IR LEDs with Smart IR, Zoom Priority, and manual control modes
- NDAA Section 889 compliant for government and regulated-site deployments
- PoE+ (802.3at) or 24 VDC power -- single-cable PoE+ install, 23W max draw
- ONVIF Profile S/G/T for integration with third-party VMS platforms including LumiViewer, CGI, and SDK
System requirements
Connects via RJ-45 (10/100 Base-T) to any PoE+ switch or 24VDC supply. LumiSearch and LumiAnalytics require a compatible Luminys NVR. Onboard storage via Micro SD (up to 512 GB); NAS and FTP/SFTP also supported. Pan and tilt control through ONVIF, Luminys SDK, or LumiViewer client.
Specifications
| SKU | LM-P55-4SA45 |
|---|---|
| Brand | Luminys |
| Form factor | PTZ dome, Mainstream Series |
| Resolution | 4MP (2560 x 1440) |
| Sensor | 1/2.8-in. 4MP Progressive CMOS |
| Zoom | 45x optical (4.0 mm to 177.8 mm) |
| Field of view | H: 65.7 to 1.9 deg | V: 39.4 to 1.1 deg | D: 73.1 to 2.1 deg |
| Minimum illumination | 0.005 Lux color / 0.0005 Lux B/W / 0 Lux with IR on |
| IR range | 492 ft (150 m), 4x IR LEDs |
| IR control | Manual, Smart IR, Zoom Priority, Off |
| Pan range | 0 to 360 deg endless |
| Tilt range | -15 to 90 deg, Auto Flip 180 deg |
| Pan speed | 0.1 to 250 deg/s manual; 250 deg/s preset |
| Tilt speed | 0.1 to 140 deg/s manual; 140 deg/s preset |
| Presets | 300 presets, 8 tours (32 presets each), 5 patterns, 5 scans |
| Power input | PoE+ (802.3at) or 24 VDC (2.5 A +/- 25%) |
| Power consumption | 23 W (Max.) |
| Communication | ONVIF (Profile S/G/T), CGI, SDK, P2P |
| Network interface | RJ-45 (10/100 Base-T) |
| Storage | Micro SD up to 512 GB, NAS, FTP/SFTP |
| Audio | 1-ch input / 1-ch output |
| Alarm I/O | 2-ch input / 1-ch output |
| Analytics | LumiSearch, LumiTracking, LumiFocus, VCA+ (Line Crossing, Intrusion, Loitering, Parking Detection), Face Detection, People Counting, Queue Management, Heat Map |
| Video compression | H.265+, H.265, H.264+, H.264, MJPEG (sub stream only) |
| Weather rating | IP67, IK10 |
| Operating temp | -40 to 158 deg F (-40 to 70 deg C) |
| Dimensions | Dia. 7.5 in. x 13.1 in. (191.0 mm x 332.0 mm) |
| Weight | 8.0 kg (17.6 lb) net |
| Housing material | Metal |
| Compliance | NDAA Section 889 |
| Certifications | FCC, IC |
| Mounting | Wall mount bracket (LUM-W02) included; optional pole, parapet, corner, pendant mounts available |
Documents and resources
FAQs
Is the P55-4SA45 NDAA Section 889 compliant?
Yes. The P55-4SA45 is NDAA Section 889 compliant and suitable for government facilities, schools, critical infrastructure, and any site with federal contract restrictions on camera sourcing.
What power options does this PTZ support?
PoE+ (802.3at) for a single-cable installation, or 24 VDC at 2.5A via a dedicated power supply. Maximum draw is 23W. Most commercial PoE+ switches will power it without a midspan injector.
Does LumiSearch require a specific NVR?
LumiSearch cross-camera AI tracking requires a Luminys LumiSearch-enabled NVR. The camera's built-in analytics -- LumiTracking, VCA+, Face Detection, People Counting -- run onboard without a specific NVR.
How far does the IR reach at night?
492 feet (150 meters) from four IR LEDs. Smart IR mode automatically adjusts intensity to prevent overexposure at close range; Zoom Priority mode keeps IR matched to the current zoom level so the target stays illuminated at full tele.
What VMS platforms does this camera support?
ONVIF Profile S, G, and T for broad third-party VMS compatibility. Native support via Luminys LumiViewer desktop and mobile client. Also supports CGI, Luminys SDK, and P2P for direct mobile access.
What mounting hardware is included, and what else is available?
A wall mount bracket (LUM-W02) ships in the box. Additional Luminys-certified mounts are available separately: parapet (LUM-R01), corner (LUM-C01), pole (LUM-P01), ceiling (LUM-E02), junction box (LUM-J10), and mount adapter (LUM-A08).
What is the operating temperature range?
-40 to 158 deg F (-40 to 70 deg C). The LumiPolarPro design enables reliable operation in extreme cold; LumiDesertPro handles high-heat environments. IP67 weather sealing and IK10 impact resistance cover outdoor and vandal-prone locations.
