IQ (Qolsys) | IQ5 NS Screen-Free PowerG+ Alarm Panel with Z-Wave 800 Long Range & Verizon LTE (Replaces IQPK084) | IQN5017

IQ (Qolsys) | IQ5 NS Screen-Free PowerG+ Alarm Panel with Z-Wave 800 Long Range & Verizon LTE (Replaces IQPK084) | IQN5017

No reviews yet Write a Review
SKU:
QO-IQN5017

The IQ5 NS gives installers a full PowerG+ alarm platform without a wall-mounted touchscreen. It's built for jobs where the end user prefers to run the system entirely from the mobile app: apartments, secondary units, closet installs, and any spec that treats the panel as network hardware rather than a wall fixture.

Screen-free, still full-featured

Under the housing: Qualcomm DragonWing processor, Android 14, PowerG+ 915MHz for up to 128 sensors, Z-Wave 800 Long Range for up to 167 automation devices, dual-band Wi-Fi with a built-in access point, Bluetooth 5.0 LE, and Verizon LTE CAT4 cellular. Every core radio is on board. The only thing missing is the touchscreen. Click here to view the AT&T version.

Key features

  • PowerG+ 915MHz built in for up to 128 sensors at 2000 ft line-of-sight, with legacy 319.5/345/433 MHz support via optional add-on cards
  • Z-Wave 800-Series Long Range for up to 167 automation devices with 4x range and 10x battery life over prior generations
  • Dual-band Wi-Fi 2.4/5GHz with a built-in access point, plus Bluetooth 5.0 LE for disarming
  • Up to 4 partitions and 242 users, managed remotely through the mobile app
  • 85 dB built-in piezo siren and dual panel/wall tamper
  • SmartMount wall bracket included, optional table stand sold separately

System requirements

Standard Alarm.com Interactive plan with cellular. 12V DC 1A power supply included. Legacy Qolsys sensor support requires the appropriate 319.5, 345, or 433 MHz add-on card, sold separately. All programming, arming, and user management happens through the Alarm.com mobile app; there is no on-panel touchscreen UI.

View the full IQ5 Lineup

Brand:
IQ (Qolsys)
Form factor:
Screen-free wall-mount alarm panel
Processor:
Qualcomm DragonWing
Operating system:
Android 14
Wireless sensor radio:
PowerG+ 915MHz, up to 128 sensors at 2000 ft LOS
Legacy RF support:
319.5, 345, or 433 MHz via optional add-on cards (sold separately)
Home automation:
Z-Wave 800-Series Long Range, up to 167 devices
Cellular:
Verizon LTE CAT4
Wi-Fi:
802.11 a/b/g/n/ac dual-band 2.4/5GHz with built-in access point
Bluetooth:
Bluetooth 5.0 LE
Storage:
32GB NAND
User interface:
Mobile app; on-panel status LEDs and single hard button
Partitions:
Up to 4
Users:
Up to 242
Siren:
85 dB built-in piezo
Audio:
Single 2W front-facing speaker
Power input:
12V DC 1000mA barrel jack (external plug-in adapter, included)
Backup battery:
18650 lithium-ion, 3000mAh
Tamper:
Dual (panel and wall)
Operating temp:
32Ā°F to 120Ā°F
Operating humidity:
Up to 93% RH, non-condensing
Compliance:
UL 985, UL 1023, UL 2610, ULC-S545, ULC-S304, FCC, IC, IFETEL
Dimensions:
6.1" H x 7.5" W x 1" D (155 x 191 x 26 mm)
Weight:
2 lb (packaged)
Mounting:
SmartMount wall bracket included; table stand sold separately
How is the IQ5 NS different from the IQ Panel 5 and IQ5 Hub?
The IQ5 NS is the screen-free member of the IQ5 family. Same radios and platform as the Panel 5 and Hub, but no 7-inch touchscreen. Users manage the system through the mobile app; the panel shows status via LEDs only.
Which cellular carrier does this variant use?
Verizon LTE CAT4 variant. See the full IQ5 lineup for AT&T options.
Does the IQ5 NS support legacy Qolsys sensors on 319.5, 345, or 433 MHz?
Yes, with the appropriate add-on card. PowerG+ 915MHz is built in. Legacy RF cards are sold separately and slot into the modular card bay.
How many sensors and Z-Wave devices does the IQ5 NS support?
Up to 128 PowerG+ wireless sensors at 2000 ft line-of-sight and up to 167 Z-Wave 800-Series Long Range automation devices.
How does the end user interact with a screen-free panel?
All arming, disarming, user setup, and event history happen through the Alarm.com mobile app. The panel shows status via two LEDs (green disarmed, red armed) and has one hard button for pairing and trouble acknowledgment.
What's the power and backup battery configuration?
12V DC 1000mA via barrel jack from an included plug-in adapter, backed by an 18650 lithium-ion 3000mAh battery.
Is a table stand available for the IQ5 NS?
The SmartMount wall bracket ships in the box. A table stand is available as a separate accessory for installs that need a desktop or countertop placement.
What certifications does the IQ5 NS carry?
UL 985 (residential fire), UL 1023 (residential burglary), UL 2610 (commercial burglary), ULC-S545 and ULC-S304, plus FCC, IC, and IFETEL.
