Genesis LED EG1 Series Compact Wall Mount Chime-Strobe, 24VDC, Red
Kidde Commercial

Genesis LED EG1 Series Compact Wall Mount Chime-Strobe, 24VDC, Red

SKU KD-EG1R-C

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The Kidde Genesis LED EG1R-C is a compact wall mount chime-strobe that delivers both audible and visual notification from one of the smallest footprints in the Genesis LED lineup. Built for commercial fire alarm circuits running 24VDC, it mounts to standard back boxes and ties into Kidde and Edwards Enhanced Integrity or Genesis NAC circuits without adapter plates or special wiring.

Built for the commercial fire alarm installer

The EG1 Series compact form factor fits where full-size appliances won't - tight corridors, small offices, and retrofit spaces where mounting real estate is limited. LED strobe technology means lower current draw per device, letting you load more appliances per NAC circuit before hitting panel limits. UL 464 and ULC-S525/S526 listed for fire alarm service in the US and Canada.

Key features

  • Compact Genesis form factor: fits standard back boxes in tight mounting locations where full-size appliances can't go
  • Dual notification: chime audible and LED strobe visual in a single appliance - fewer devices on the wall, fewer wire runs
  • LED strobe technology: lower current draw per appliance means more devices per NAC circuit
  • 16-33 VDC operating range: works on regulated or unregulated (filtered) DC notification circuits
  • Genesis sync compatible: synchronizes with other Genesis appliances on the same NAC circuit for code-compliant temporal patterns
  • UL and ULC listed: fire alarm notification service in the US and Canada

System requirements

Connects to any Kidde or Edwards fire alarm control panel with a 24VDC notification appliance circuit (NAC). Uses 12-18 AWG field wiring. Mounts to a standard 4-inch square electrical box or single-gang box with appropriate adapter plate. Indoor use only - operating temperature 32F to 120F, 0-93% RH non-condensing.

Specifications

SKUKD-EG1R-C
BrandKidde Commercial
Form factorCompact wall mount notification appliance, Genesis LED EG1 Series
Power input16-33 VDC (nominal 24VDC), regulated or unregulated (filtered) DC
Wire size12-18 AWG
Notification typeChime (audible) + LED Strobe (visual)
Operating temp32°F to 120°F (0°C to 49°C)
Operating humidity0-93% RH, non-condensing
MountingWall mount, standard back box
SynchronizationGenesis sync protocol
Housing colorRed
ComplianceUL 464, ULC-S525, ULC-S526
EnvironmentIndoor use only
CompatibilityKidde and Edwards Enhanced Integrity and Genesis NAC circuits

Documents and resources

FAQs

Does this fit where a full-size Genesis appliance won't?
Yes. The EG1 is the compact form factor in the Genesis LED lineup. Mounts to standard 4-inch square or single-gang back boxes, fitting tight corridors, small offices, and retrofit spaces where full-size appliances won't go.
What fire alarm panels is this compatible with?
Any Kidde or Edwards fire alarm control panel (FACP) with a 24VDC notification appliance circuit (NAC). Compatible with Enhanced Integrity and Genesis notification circuits.
Does the strobe synchronize with other Genesis appliances?
Yes. The LED strobe synchronizes with other Genesis and Genesis LED appliances on the same NAC circuit using the Genesis sync protocol, meeting NFPA 72 requirements for synchronized visible notification.
Can I use this outdoors?
No. The EG1R-C is rated for indoor use only - operating temperature 32°F to 120°F, humidity 0-93% non-condensing. For outdoor applications, see the Genesis Outdoor series (Kidde part numbers beginning with EGO).
What wire size does this require?
Standard 12 to 18 AWG field wiring. Accepts regulated or unregulated (filtered) DC from the NAC circuit, operating range 16-33 VDC.
