Fireray One Auto-Aligning Reflective Beam Smoke Detector, 50M Range, IP55, UL/ULC
Kidde Commercial

Fireray One Auto-Aligning Reflective Beam Smoke Detector, 50M Range, IP55, UL/ULC

SKU KD-6010-300

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The Fireray One covers open areas up to 164 feet with a single reflective beam path and aligns itself in under a minute. Mount the detector on one wall and the prismatic reflector on the opposite wall, aim the integrated laser, and the motorized optics handle fine alignment automatically. One person, no specialist tools, no ladder time spent chasing signal strength.

Built for the commercial installer

Building Movement Tracking continuously compensates for structural shifts over time, eliminating re-alignment callbacks that plague conventional beam detectors. The detector draws just 5 mA from any 14-36 VDC source, making it compatible with standard fire alarm panel auxiliary outputs. IP55-rated polycarbonate housing handles dusty warehouses, atriums, and loading docks. UL and ULC listed.

Key features

  • One Minute Auto-Alignment: motorized optics find optimal beam path after initial laser aim, no manual tweaking
  • Building Movement Tracking: continuous motorized micro-adjustments compensate for structural shifts without service calls
  • 164 ft detection range standard, extendable to 394 ft with the optional Long Range Kit
  • IP55 weather rating for dusty, humid, or temperature-variable commercial environments
  • Four programmable alarm thresholds from 25% (fastest response) to 85% (highest false-alarm immunity)
  • 5 mA normal draw from 14-36 VDC - runs off panel aux power with headroom to spare

System requirements

Requires a compatible conventional fire alarm control panel with supervised zone input. The detector connects to the panel's initiating device circuit and draws power from a 14-36 VDC auxiliary output. Reflective prism panel included. For ranges beyond 164 ft, order the optional Long Range Kit separately.

Specifications

SKUKD-6010-300
BrandKidde Commercial
Form factorReflective beam smoke detector with prismatic reflector panel
Detection range16 to 164 ft (5 to 50 m), extendable to 394 ft (120 m) with Long Range Kit
Power input14 to 36 VDC
Current draw5 mA normal operation, 33 mA fast alignment mode
Optical wavelength850nm near infrared (detection), 650nm visible (alignment laser)
Alarm thresholds25% (1.25 dB), 35% (1.87 dB, default), 55% (3.46 dB), 85% (8.23 dB) obscuration
Delay to alarm10 seconds
Delay to fault10 seconds
Operating temp-4°F to 131°F (-20°C to 55°C)
Storage temp-40°F to 185°F (-40°C to 85°C)
Operating humidity0 to 93%, non-condensing
Weather ratingIP55
Detector dimensions5.12 × 7.13 × 5.28 in (130 × 181 × 134 mm)
Detector weight1.55 lb (0.7 kg)
Reflector dimensions3.94 × 3.94 × 0.36 in (100 × 100 × 9 mm)
Reflector weight0.22 lb (0.1 kg)
Housing materialUL94 V0 Polycarbonate
Housing colorWhite (RAL9016)
Max detector alignment±4.5°
Max reflector misalignment±5°
ComplianceUL, ULC

Documents and resources

FAQs

What detection range does the Fireray One cover?
16 to 164 ft (5 to 50 m) standard. The optional Long Range Kit extends coverage to 394 ft (120 m) for larger atriums, warehouses, and open-plan spaces.
Does the Fireray One require special tools to install?
No. The integrated visible laser guides initial aim at the reflector, then One Minute Auto-Alignment handles motorized fine adjustment. One person, no specialist tools, no signal meter.
How does Building Movement Tracking work?
The detector continuously monitors beam signal strength and makes motorized micro-adjustments to compensate for natural structural shifts in the building over time. No manual re-alignment or service calls needed.
What power supply does the Fireray One need?
14 to 36 VDC, drawing just 5 mA in normal operation. Compatible with standard fire alarm panel auxiliary power outputs - no dedicated power supply required.
Is the Fireray One rated for harsh environments?
IP55 rated with an operating temperature range of -4°F to 131°F (-20°C to 55°C) and humidity tolerance up to 93% non-condensing. Suitable for warehouses, loading docks, atriums, and other challenging commercial spaces.
What alarm sensitivity options are available?
Four programmable alarm thresholds: 25% (1.25 dB, fastest response), 35% (1.87 dB, default), 55% (3.46 dB, high immunity), and 85% (8.23 dB, highest immunity to false alarms). Adjustable via configuration switches on the detector.
