The SIGA-AA30 is a 30 watt intelligent audio amplifier that talks to the panel over the Signature or GSA data circuit instead of a dedicated audio riser home run, so smaller voice evacuation zones can be added without a new wiring path back to the rack. Two riser inputs and selectable 25/70 Vrms output give it the flexibility to slot into most existing distributed audio designs.
Built for the commercial installer
- 30 watt output with selectable 25 or 70 Vrms
- Two riser inputs, 1 or 25 Vrms
- Communicates over Signature or GSA data circuit - no separate audio data run required
- Mounts in 2-WB3(R), 2-WB7(R), or RACCR enclosures
Brand:
Kidde Commercial
Output power:
30 Watt, selectable 25/70 Vrms
Riser inputs:
Two, 1 or 25 Vrms
Communication:
Signature or GSA data circuit
Mounting:
2-WB3(R), 2-WB7(R), or RACCR enclosure
Spec Sheet
