Kidde | Intelligent 30 Watt Audio Amplifier, Signature/GSA Data Circuit | SIGA-AA30

Intelligent 30 Watt Audio Amplifier, Signature/GSA Data Circuit

SKU KD-SIGA-AA30

Fast shipping from four branches
30-day returns on unopened products

Questions? Call us 866-364-0030The SS&Si dealer team

The SIGA-AA30 is a 30 watt intelligent audio amplifier that talks to the panel over the Signature or GSA data circuit instead of a dedicated audio riser home run, so smaller voice evacuation zones can be added without a new wiring path back to the rack. Two riser inputs and selectable 25/70 Vrms output give it the flexibility to slot into most existing distributed audio designs.

Built for the commercial installer

30 watt output with selectable 25 or 70 Vrms
Two riser inputs, 1 or 25 Vrms
Communicates over Signature or GSA data circuit - no separate audio data run required
Mounts in 2-WB3(R), 2-WB7(R), or RACCR enclosures

Specifications

SKU	KD-SIGA-AA30
Brand	Kidde Commercial
Output power	30 Watt, selectable 25/70 Vrms
Riser inputs	Two, 1 or 25 Vrms
Communication	Signature or GSA data circuit
Mounting	2-WB3(R), 2-WB7(R), or RACCR enclosure
