The GSA-MM1 is an addressable monitor module that puts a single normally-open, dry-contact initiating device — a tamper switch, waterflow contact, or third-party detector — on the signaling line circuit as its own supervised point.
Built for the commercial installer
The module needs no address switches; the loop controller assigns and downloads the address and operating personality electronically, which speeds commissioning and eliminates dial-in errors on the bench. A bicolor LED gives a quick normal/alarm read at the module without pulling up the panel's device list.
Key features
- Single Class B, normally-open dry-contact input — factory set for non-latching monitor operation
- Electronic addressing — no address switches to set in the field
- Bicolor status LED for at-a-glance normal (green) / alarm (red) indication
- Mounts to standard 1-gang or 4" square electrical boxes for flexible placement
- UL 864 listed for commercial fire alarm systems
System requirements
Requires a compatible Kidde addressable signaling line circuit (SLC) loop controller. Does not support conventional smoke detectors.
Brand:
Kidde Commercial
Form factor:
Single-input addressable monitor module
Communication:
Analog addressable SLC loop, electronic addressing (no switches)
Initiating line circuit:
Class B, Style 4, normally-open dry contact
Wire size:
12 to 18 AWG (0.75 to 2.5 sq. mm)
Compatible electrical boxes:
2-1/2" deep single-gang box or 4" square box, 1-1/2" deep, with single-gang cover
Operating temp:
32ĆĀ°F to 120ĆĀ°F (0ĆĀ°C to 49ĆĀ°C)
Operating humidity:
0 to 93% RH, noncondensing
Compliance:
UL 864, FCC Part 15
What does the GSA-MM1 monitor?
A single Class B, normally-open, dry-contact circuit -- tamper switches, waterflow contacts, or other third-party dry-contact devices -- as one supervised addressable point.
Does the GSA-MM1 need address switches set?
No. The loop controller assigns and downloads the module's address and operating personality electronically; there are no address switches to configure by hand.
Will this work with a conventional smoke detector?
No. The module does not support conventional (non-addressable) smoke detectors -- it is a dry-contact monitor module only.
