The Kidde Genesis LED EG4ARF is a wall-mount fire alarm horn in red with FIRE marking. Part of the Genesis LED EG4 Series, it delivers up to 92 dBA output in a low-profile housing that protrudes only 1.5 inches from the mounting surface - keeping hallways and corridors clean while meeting code requirements.

Built for the commercial fire alarm installer

The EG4 mounts to any standard 1-gang, 2-gang, 3.5-inch octagon, or 4-inch square electrical box using the included GP10 room side wiring plate. Pre-install and pre-wire the plate, snap the device into place, and you're done - no visible mounting screws on the finished install. Field-selectable high or low dB output and constant or TC3 temporal tone patterns let you configure on the job without swapping hardware. UL and ULC listed.

Key features

  • Up to 92 dBA output with improved audio frequency range for better wall and door penetration
  • Field-selectable sound output: high or low dB, constant or TC3 temporal via slide switches under the cover
  • Low-profile design protrudes only 1.5 inches from the wall with no visible mounting screws
  • Room side wiring plate included: pre-install, pre-wire, and run diagnostics before the device goes on
  • Fits standard electrical boxes: 1-gang, 2-gang, 3.5-inch octagon, and 4-inch square
  • Backwards compatible with existing Xenon-based Genesis appliances on the same NAC circuit

Compatibility

Works with Kidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, and both Intelligent and Conventional Fire Alarm Control Panels. Compatible with coded and non-coded notification appliance circuits.

Specifications

SKUKD-EG4ARF
BrandKidde Commercial
Form factorWall mount horn, low-profile (1.5" protrusion)
Operating voltage16 to 33 VDC, 16 to 33 VFWR
Sound output (high dB)92 dBA anechoic, 85 dBA reverberant (UL 464)
Sound output (low dB)86 dBA anechoic, 80 dBA reverberant (UL 464)
Horn signal typeConstant or TC3 temporal, field-selectable
Current draw (high dB)28 mA (VDC), 38 mA (VFWR)
Current draw (low dB)18 mA (VDC), 22 mA (VFWR)
Wire size12 to 18 AWG (0.75 to 2.50 mm²)
Compatible electrical boxes1-gang, 2-gang, 3.5-inch octagon, 4-inch square (min 1.5" deep)
MountingGP10 room side wiring plate (included)
ColorRed
MarkingFIRE
Dimensions4.95 x 5.78 x 1.62 in (12.57 x 14.68 x 4.11 cm)
Operating temp32 to 122°F (0 to 50°C)
Operating humidity0 to 93% noncondensing
Storage temp-40 to 158°F (-40 to 70°C)
ComplianceUL (UL 464), ULC, FCC
Optional trim platesEG4TR (red), EG4TW (white)

Documents and resources

FAQs

Can this horn be mixed with existing Xenon-based Genesis devices on the same circuit?
Yes. Genesis LED EG4 horns are backwards compatible with legacy Xenon-based Genesis appliances and can run on the same NAC circuit without replacing existing devices.
What electrical boxes does the EG4ARF fit?
Standard 1-gang, 2-gang, 3.5-inch octagon, and 4-inch square electrical boxes. Boxes must be at least 1-1/2 inches (3.81 cm) deep.
Can the sound output be changed in the field?
Yes. Slide switches under the cover select high or low dB output and constant or TC3 temporal tone patterns. No need to remove the device from the wall.
Does this horn work with coded NAC circuits?
Yes. Horn-only models like the EG4ARF can be configured for either coded or non-coded notification appliance circuits.
What control panels and signal sources are compatible?
The EG4ARF works with Kidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, and both Intelligent and Conventional Fire Alarm Control Panels.
