Genesis LED EG4LF Low Frequency Wall Horn-Strobe, 15/30/75/110 cd, White, FIRE Marking
Kidde Commercial

Genesis LED EG4LF Low Frequency Wall Horn-Strobe, 15/30/75/110 cd, White, FIRE Marking

SKU KD-EG4LFVWF

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The Kidde Genesis LED EG4LF drops 520 Hz low-frequency notification into commercial sleeping areas - hotels, dorms, assisted living - where NFPA 72 mandates the low-frequency tone to wake occupants. LED strobe technology draws significantly less current than legacy Xenon strobes, so you fit more devices on each NAC circuit and spend less time calculating power supply loads.

Built for the commercial fire installer

UL 464 and UL 1971 listed. Field-selectable candela (15/30/75/110 cd) and sound output (high/low) mean one SKU covers a range of room sizes without reordering. The GRSW room-side wiring plate (included) lets you pre-wire, verify continuity, and install the device later - no return trips to close out the rough-in.

Key features

  • 520 Hz low-frequency tone: meets NFPA 72 Chapter 18 for sleeping area notification where standard 3 kHz signals fall short
  • LED strobe technology: lower current draw per device means fewer booster power supplies and smaller wire runs on the same NAC circuit
  • Field-selectable output: 15, 30, 75, or 110 cd strobe and high/low dB horn - one part number, multiple applications
  • Universal mounting: fits 1-gang, 2-gang, 4-inch square, and 4-inch octagon boxes (GOCT adapter available for octagon)
  • Room-side wiring plate included: pre-wire to the GRSW plate, verify NAC integrity, snap the device on when the room is finished
  • Genesis LED sync protocol: keeps multiple strobes on the same circuit synchronized per NFPA 72 requirements

System requirements

Operates on regulated or unregulated 16-33 VDC NAC circuits from compatible Kidde Commercial intelligent or conventional fire alarm control panels. Synchronization requires CC1S or MCC1S Series Signal Modules, compatible Booster or Auxiliary Power Supplies, or panels with built-in Genesis LED sync.

Specifications

SKUKD-EG4LFVWF
BrandKidde Commercial
Form factorWall-mount horn-strobe
Horn frequency520 Hz (low frequency)
Horn signal patternConstant or TC3 temporal, field-selectable
Sound output78 dBA (low) / 83 dBA (high) at 10 ft
Strobe candela15, 30, 75, or 110 cd (field-selectable)
Strobe flash rate1 fps per UL 1971
Operating voltage16-33 VDC or 16-33 VFWR
Current draw (DC, 110 cd)159 mA max (high horn) / 145 mA max (low horn)
Wire size12-18 AWG
Mounting1-gang, 2-gang, 4-inch square, 4-inch octagon (with GOCT adapter)
Operating temp32°F to 122°F (0°C to 50°C)
Operating humidity0-93% noncondensing
Housing colorWhite (RAL 9002)
Lens markingFIRE
Dimensions4.95 x 5.78 x 1.62 in (W x H x D)
ComplianceUL 464, UL 1971, FCC Part 15, IC (ICES-003), RoHS
Environmental classIndoor, dry
Included accessoriesGRSW room-side wiring plate
SynchronizationCC1S/MCC1S Series Signal Modules, compatible Booster/Auxiliary Power Supplies, or panels with built-in Genesis LED sync

Documents and resources

FAQs

Does this horn-strobe meet NFPA 72 for sleeping areas?
Yes. The 520 Hz low-frequency tone meets NFPA 72 Chapter 18 requirements for audible notification in sleeping areas, including hotels, dormitories, and assisted living facilities. Standard 3 kHz horns do not satisfy this requirement.
How many devices fit on one NAC circuit?
Depends on panel and power supply capacity. LED strobes draw less than Xenon. At 110 cd DC, the EG4LFVWF draws 159 mA (high) or 145 mA (low). See spec sheet current draw tables to size your circuit.
Can I mix this with standard-frequency Genesis LED devices on the same NAC?
Yes. Low-frequency and standard-frequency Genesis LED devices can share the same synchronized NAC circuit. The sync protocol handles both types, and each device outputs its own frequency independently.
What boxes does this mount on?
Standard 1-gang, 2-gang, and 4-inch square boxes. For 4-inch octagon boxes, use the GOCT adapter plate (ordered separately). The included GRSW wiring plate fits all supported box types.
What synchronization source do I need?
CC1S or MCC1S Series Signal Modules, compatible Kidde Booster or Auxiliary Power Supplies, or panels with built-in Genesis LED sync. All devices on a circuit must share a common sync source.
Can I use the room-side wiring plate for pre-wiring?
Yes. The included GRSW plate mounts to the backbox and accepts 12-18 AWG wiring. Complete and test wiring before the device arrives, then snap the horn-strobe onto the plate to finish the install.
