Genesis LED EG4 Series Wall Mount Speaker/Strobe, 15/30/75/110 cd Field-Selectable, White, ALERT Marking
Kidde Commercial

Genesis LED EG4 Series Wall Mount Speaker/Strobe, 15/30/75/110 cd Field-Selectable, White, ALERT Marking

SKU KD-EG4SVWA

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The Kidde Genesis LED EG4 Speaker/Strobe combines a high-fidelity speaker with a field-selectable LED strobe in a single wall-mount package, cutting your notification appliance count and wire runs in half. Built for commercial fire alarm systems on regulated 24 VDC, it mounts on any standard 4-inch square electrical box and ships with the room-side wiring plate (GP10) so rough-in wiring stays accessible after trim-out.

Built for the commercial fire alarm installer

The EG4 Series uses LED strobe technology for lower current draw and longer service life compared to xenon-based appliances. Four candela settings (15, 30, 75, 110 cd) and four speaker wattage taps (1/4W, 1/2W, 1W, 2W) are field-selectable without tools, so one SKU covers multiple AHJ requirements and NAC circuit loading scenarios. Audio output runs on 25V or 70.7V RMS, also field-selectable. UL 1971 and UL 1480 listed. ULC-S526 and ULC-S525 listed for Canadian installations.

Key features

  • Single-appliance coverage: speaker and strobe in one device reduces box count and conduit runs on the job
  • Field-selectable candela (15/30/75/110 cd): adjust strobe intensity to match ADA and NFPA 72 spacing requirements without swapping hardware
  • Field-selectable wattage (1/4W, 1/2W, 1W, 2W): dial in NAC circuit loading without returning to the truck
  • LED strobe technology: lower current draw per candela setting, longer lifespan, no xenon tube replacements
  • Genesis synchronization: all strobes on the circuit flash in unison per NFPA 72 and UL 1971 requirements
  • Room-side wiring plate (GP10) included: access field wiring from the front after the device is trimmed out

System requirements

Connects to a regulated 24 VDC NAC circuit from a compatible FACP or NAC power supply. Mounts on a standard 4-inch square electrical box with single-gang or double-gang adapter plate. Wire gauge: 12-18 AWG. Indoor use only.

Specifications

SKUKD-EG4SVWA
BrandKidde Commercial
Form factorWall mount speaker/strobe
Power inputRegulated 24 VDC (filtered DC or FWR)
CommunicationNAC circuit (supervised)
Speaker wattage1/4W, 1/2W, 1W, 2W (field selectable)
Audio voltage25V or 70.7V RMS (field selectable)
Strobe candela15, 30, 75, 110 cd (field selectable)
Strobe technologyLED
SynchronizationGenesis sync protocol
ColorWhite
MarkingALERT
Operating temp32°F to 120°F (0°C to 49°C)
Operating humidity0% to 93% non-condensing
Wire gauge12-18 AWG
MountingStandard 4" square electrical box
ComplianceUL 1971, UL 1480, ULC-S526, ULC-S525
UseIndoor only
Included accessoriesRoom-side wiring plate (GP10)

Documents and resources

FAQs

What candela settings does this speaker/strobe support?
Four field-selectable settings: 15, 30, 75, and 110 cd. Adjust via switches on the device to meet ADA and NFPA 72 spacing requirements without changing hardware.
Does this synchronize with other Genesis notification appliances?
Yes. The EG4 Series synchronizes with other Genesis notification appliances on the same NAC circuit per UL 1971 requirements. All strobes on the circuit flash in unison.
What speaker wattage taps are available?
Four field-selectable taps: 1/4W, 1/2W, 1W, and 2W. The device also supports 25V or 70.7V RMS audio, field-selectable, to match your FACP or amplifier output.
What box does this mount on?
Standard 4-inch square electrical box with single-gang or double-gang adapter plate. The GP10 room-side wiring plate is included for front-accessible field wiring after trim-out.
Is this rated for outdoor use?
No. The EG4 Series is rated for indoor use only (32°F to 120°F operating temperature). For outdoor applications, see the Kidde Genesis LED outdoor speaker and strobe models.
Is this UL and ULC listed?
Yes. UL 1971 (strobe), UL 1480 (speaker), ULC-S526, and ULC-S525 listed for installations in the US and Canada.
