The Luminys ED1CU is a USB-powered MIFARE card enrollment reader for issuing and reading 13.56 MHz IC cards during commissioning or ongoing user management. Plug-and-play over USB 2.0, powered from the host at 5 VDC.
Purpose-built for enrollment workstations
The reader sits on the desk at a workstation or in an office where credentials are provisioned. LED indicators call out success and failure states (green for card issued, red for abnormal operation) and a built-in buzzer confirms card actions audibly. Card issuing distance is 1.2 to 2.0 inches, tight enough to prevent stray reads at busy enrollment desks.
Key features
- MIFARE (IC) card read and issue at 13.56 MHz
- USB 2.0 plug-and-play with any Luminys access management workstation
- Bus-powered: 5 VDC, 0.5 A from the USB port
- LED status indicator (green normal / red abnormal) and built-in buzzer
- NDAA compliant, FCC certified
Brand:
Luminys
Form factor:
Desktop USB card enrollment reader
Card type:
MIFARE IC card, 13.56 MHz
Card issuing distance:
1.2 in to 2.0 in (3.0 cm to 5.0 cm)
Status feedback:
LED (green normal, red abnormal), built-in buzzer
Interface:
USB 2.0
Power supply:
5 VDC, 0.5 A (USB bus-powered)
Power consumption:
Standby ā¤1.0W, Working ā¤1.7W
Operating temp:
-22Ā°F to 140Ā°F (-30Ā°C to 60Ā°C)
Operating humidity:
5% to 95% RH, non-condensing
Casing material:
PC and ABS
Dimensions:
4.1" x 3.0" x 0.8" (105 x 75 x 20 mm)
Weight:
0.4 lb (0.2 kg)
Certifications:
FCC, NDAA compliant
What card format does the ED1CU read?
MIFARE IC cards at 13.56 MHz. It both reads existing cards and issues new ones for enrollment.
Does it require external power?
No. The reader is USB 2.0 bus-powered at 5 VDC, 0.5 A. Just plug it into the enrollment workstation.
How does the reader signal success or failure?
A green LED and buzzer confirm a successful card issue. A red LED signals abnormal operation or a failed issue attempt.
Is the ED1CU NDAA compliant?
Yes. NDAA compliant and FCC certified.
