Omada 5-Port Gigabit Smart PoE+ Passthrough Switch, PoE++ In, 4 PoE+ Out, IP66 Outdoor
SKU TPL-SG2005P-PD Model SG2005P-PD
- One PoE++ input powers the switch and passes PoE+ out to four Gigabit ports
- Output budget of 64 W, 44 W, 19 W or 6 W depending on the PoE source feeding it
- IP66 dustproof, waterproof, UV-resistant case rated -40°F to 140°F
- Pole or wall mount kit included, managed in Omada with zero-touch provisioning
- Fast shipping from four branches
- 30-day returns on unopened products
Product highlights
- Ports5 x Gigabit, 4 PoE+ out
- PoE64 W out from 90 W PoE++ in
- PowerPowered by PoE in, no AC
- MountPole or wall, IP66
- Size4.1 x 1.6 x 7.3 in
The Omada SG2005P-PD is a 5-port Gigabit Smart switch that runs off a single PoE++ feed, so you can put cameras and access points out at the pole or the building corner without pulling AC power. It takes PoE in on port 5 and passes PoE+ out on four ports, with an IP66 weatherproof enclosure.
Built for outdoor camera and AP runs
PoE passthrough doubles the source-to-device distance from 100 m to 200 m at Gigabit speed, which covers long camera runs. The output budget depends on the PoE source: up to 64 W from an 802.3bt Type 4 (90 W) feed, 44 W from Type 3 (60 W), 19 W from 802.3at and 6 W from 802.3af. The enclosure is dustproof, waterproof and UV-resistant, rated for -40°F to 140°F, and mounts to a wall or pole with the included kit. VLANs, ACLs, QoS and static routing are available when the site needs segmentation.
Key features
- PoE++ in, 4 PoE+ out: one 802.3af/at/bt feed on port 5 powers the switch and the devices on ports 1 to 4
- Up to 64 W of output: when fed from an 802.3bt Type 4 (90 W) source; the budget scales down with the input
- IP66 weatherproof case: dustproof, waterproof and UV-resistant, -40°F to 140°F operating range
- Wall or pole mount: mounting bracket, pole strap, anchors and screws included
- Perpetual PoE and Fast PoE: powered devices stay up through a switch reboot and come up early on a cold start
- Omada cloud management: zero-touch provisioning and batch firmware upgrades through the cloud controller
System requirements
Powered only by PoE in on port 5 (802.3af, 802.3at or 802.3bt); there is no AC adapter. Centralized management needs an Omada Cloud-Based Controller (firmware 5.15.22 or later), Omada hardware controller or Omada Software Controller (5.15.20 or later); zero-touch provisioning needs the cloud controller. Without a controller the switch runs standalone from its own web interface and CLI.
Specifications
| SKU | TPL-SG2005P-PD |
|---|---|
| Brand | TP-Link |
| Form factor | 5-port Gigabit Smart outdoor PoE passthrough switch (PoE++ in, PoE+ out), pole or wall mount |
| Communication | Ethernet / IP |
| Power input | PoE in on port 5 (802.3af/at/bt); no AC adapter |
| Power consumption | 71.05 W max when powered by 802.3bt Type 4 (90 W) |
| Management | Smart |
| PoE | 802.3af PoE |
| PoE | 802.3at PoE+ |
| PoE | 802.3bt PoE++ |
| Port speed | Gigabit |
| Works with | Omada |
| Ethernet ports | 5 x Gigabit RJ45 (port 5 PoE in, ports 1-4 PoE+ out) |
| PoE budget | 64 W with 802.3bt Type 4 (90 W) in, 44 W with Type 3 (60 W), 19 W with 802.3at, 6 W with 802.3af |
| PoE features | PoE passthrough, PoE extend mode, Perpetual PoE, Fast PoE; PoE in on port 5, PoE out on ports 1-4 |
| Switching capacity | 10 Gbps |
| Packet forwarding rate | 7.44 Mpps |
| MAC address table | 8K |
| Jumbo frame | 9 KB |
| VLANs | 4K 802.1Q VLAN groups, MAC, protocol and voice VLAN, GVRP |
| L2+ features | 32 IPv4/IPv6 static routes, DHCP server and relay, link aggregation with LACP, STP/RSTP/MSTP, loopback detection |
| Security | 802.1X, RADIUS AAA, ACLs, DHCP snooping, ARP inspection, port security, storm control |
| Controller management | Omada Cloud-Based (v5.15.22+), hardware or Software Controller (v5.15.20+); Omada app |
| Communication notes | Web GUI, CLI through Telnet, SNMP v1/v2c/v3, RMON, LLDP/LLDP-MED, IGMP snooping, IPv6 |
| Cooling | Fanless |
| Surge protection | ±6 kV |
| Mounting | Pole or wall mount (mounting kit included) |
| Dimensions | 4.1 x 1.6 x 7.3 in (103.0 x 41.6 x 186.2 mm) |
| Operating temp | -40°F to 140°F (-40°C to 60°C) |
| Operating humidity | 10 to 90% RH, non-condensing |
| Compliance | CE, FCC; IP66 enclosure |
| Package contents | SG2005P-PD, wall mount bracket, pole mount strap, wall anchors, screws, installation guide |
