Ethernet Programming/Diagnostics Interface RJ45 mounts to base plate
Kidde Commercial

Ethernet Programming/Diagnostics Interface RJ45 mounts to base plate

SKU KD-SA-ETH

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The SA-ETH card gives a compatible Kidde fire alarm panel a standard 10/100 Ethernet connection for uploading and downloading panel configuration, history, and status to a PC running the configuration utility, or for connecting to a compatible central monitoring station receiver over the network.

Built for the commercial fire installer

The card mounts to the panel's plastic assembly and connects to the main circuit board through a single ribbon cable, so installation is a bracket-and-cable job rather than a full board swap. Four status LEDs (link, speed, duplex, collision) give a quick read on network health right at the card, and the card must be configured through panel programming before it's live on the network.

Key features

  • Standard 10/100 Base-T Ethernet with RJ-45 connector, auto-negotiation
  • Remote programming and diagnostics — upload/download configuration, history, and status over the network instead of an on-site laptop connection
  • Central station connectivity — connect to a compatible monitoring receiver over the network
  • Four on-board status LEDs for link, speed, duplex, and collision at a glance
  • 200 ft. max. run from panel to network equipment on Cat 5 cable

System compatibility

Installs on the plastic assembly of a compatible Kidde/Edwards fire alarm panel, connecting to the main circuit board's J1 connector via ribbon cable (P/N 7140189). Requires panel programming for proper operation.

Specifications

SKUKD-SA-ETH
BrandKidde Commercial
Form factorEthernet interface card, panel plastic assembly mount
Ethernet10/100 Base-T, auto-negotiation, RJ-45 connector
Operating voltage / current24 VDC; 34 mA standby/alarm, 41 mA max.
Wire run200 ft. (60 m) max., Cat 5 cable, panel to communication equipment
Default IP address192.168.001.003, subnet 255.255.255.0
Connection methodRibbon cable (P/N 7140189) to main circuit board connector J1
Operating temp / humidity32 to 120°F (0 to 49°C), 0 to 93% noncondensing at 90°F (32°C)
Environmental classUL: Indoor dry

Documents and resources

FAQs

What does the SA-ETH do?
It adds a standard 10/100 Ethernet connection to a compatible fire alarm panel for remote programming, diagnostics, history uploads, and connection to a compatible central monitoring receiver over a network.
How does the card connect to the panel?
It mounts to the panel's plastic assembly and connects to the main circuit board via a ribbon cable at connector J1, located at the top-right of the main board.
Does the card need to be programmed after installation?
Yes. The SA-ETH must be configured through panel programming before it functions on the network.
What's the maximum cable run to network equipment?
200 ft. (60 m) using standard Cat 5 cable from the panel to the network equipment (PC, router, or switch).
