Genesis LED EG4 Wall Mount Speaker/Strobe, 15-110cd Selectable, White, FIRE Marking
Kidde Commercial

Genesis LED EG4 Wall Mount Speaker/Strobe, 15-110cd Selectable, White, FIRE Marking

SKU KD-EG4SVWF

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The Genesis LED EG4SVWF is a wall-mount speaker/strobe that delivers voice evacuation audio and visual strobe notification from a single appliance. Selectable candela output (15, 30, 75, or 110 cd) lets you match the notification zone without swapping models. Mounts to standard 1-gang, 2-gang, 3.5-inch octagon, or 4-inch square electrical boxes with the GP10 room-side wiring plate included for pre-wire convenience.

Built for the commercial fire installer

The EG4 Series uses LED strobe technology that draws less current per device than legacy xenon-type strobes, putting more appliances on each NAC circuit and reducing booster power supply requirements. LED and xenon Genesis strobes can share the same synchronized circuit, so you can upgrade jobs incrementally without ripping and replacing. Strobe synchronization meets UL requirements (within 10 ms over a two-hour period) when used with Kidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, or Intelligent and Conventional Control Panels.

Key advantages

  • Combined speaker and strobe in one device - reduces box count and wiring runs on voice evacuation systems
  • Field-selectable 15/30/75/110 cd strobe output - slide switch accessible from the left side without removing the device from the wall
  • LED strobe technology - lower current draw means more devices per NAC circuit and fewer booster power supplies
  • Backward compatible - mix EG4 LED and legacy xenon Genesis strobes on the same synchronized circuit
  • Room-side wiring plate (GP10) included - pre-wire and snap the device into place; built-in check bar confirms correct wiring before powering up
  • Low-profile design - protrudes about 1.5 inches from the mounting surface with no visible mounting screws

Mounting and serviceability

Fits standard 1-gang, 2-gang, 3.5-inch octagon, and 4-inch square electrical boxes (minimum 1-1/2 inch deep). Optional EG4TW white trim plate covers oversized box openings. Under-cover diagnostic test points let you check the circuit without pulling the device off the wall. Accepts 12-18 AWG in-out screw terminals.

Specifications

SKUKD-EG4SVWF
BrandKidde Commercial
Form factorWall mount speaker/strobe, low profile
Power input16 to 33 VDC or 16 to 33 VFWR
Strobe output15, 30, 75, or 110 cd (field selectable)
Strobe technologyHigh-performance LED
Strobe flash rate1 fps (approx.)
SynchronizationUL compliant, within 10 ms over 2 hours; 20 ohm max between devices
Sync sourcesKidde CC Series Signal Modules, Booster/Auxiliary Power Supplies, Intelligent and Conventional Control Panels
Housing colorWhite
Housing markingFIRE
Wire size12 to 18 AWG (0.75 to 2.50 mm²)
Compatible electrical boxes1-gang, 2-gang, 3.5" octagon, 4" square (min. 1-1/2" deep)
Mounting plateGP10 room-side wiring plate (included)
Trim platesEG4TW white (optional, sold separately)
Dimensions4.95 x 5.78 x 1.62 in (12.57 x 14.68 x 4.11 cm) (W x H x D)
Operating temp32°F to 122°F (0°C to 50°C)
Operating humidity0 to 93% non-condensing
Storage temp-40°F to 158°F (-40°C to 70°C)
EnvironmentIndoor use only
ComplianceUL listed (S298, S5389)

Documents and resources

FAQs

How many EG4 speaker/strobes fit on one NAC circuit?
Depends on FACP NAC amperage and the device's current draw at your selected settings. EG4 LED strobes draw less than xenon types, fitting more devices per circuit. Check the spec sheet current draw table against your panel's NAC rating.
Can I change the candela setting after installation?
Yes. A slide switch on the left side sets candela to 15, 30, 75, or 110 cd. The selected setting stays visible through a window when the cover is closed. No need to remove the device from the wall.
Can I mix EG4 LED strobes with older xenon Genesis strobes?
Yes. EG4 LED and legacy xenon Genesis strobes synchronize on the same NAC circuit. Add EG4 devices to existing Genesis installations without replacing older appliances.
What fire alarm panels work with this device?
Compatible with Kidde Intelligent and Conventional Fire Alarm Control Panels. Sync sources include CC Series Signal Modules and Booster/Auxiliary Power Supplies. Non-Kidde panels work if NAC output is 16-33 VDC or 16-33 VFWR.
Is a back box included?
No. Mounts to standard 1-gang, 2-gang, 3.5" octagon, or 4" square boxes (min. 1-1/2" deep). The GP10 room-side wiring plate IS included. Optional 27T93-26 white surface-mount box available separately.
