Genesis LED EG4 Wall Speaker/Strobe, 15-110 cd Selectable, Red, FIRE Marking
Kidde Commercial

Genesis LED EG4 Wall Speaker/Strobe, 15-110 cd Selectable, Red, FIRE Marking

SKU KD-EG4SVRF

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The Genesis LED EG4SVRF is a wall-mount speaker/strobe that combines audible voice and tone output with a high-efficiency LED strobe on a single NAC circuit. Selectable 15, 30, 75, or 110 cd strobe output and field-configurable speaker wattage taps let you dial in the right coverage without swapping hardware. Red housing with FIRE marking. Room side wiring plate (GP10) included for pre-wire and continuity verification before the device snaps into place.

Built for the commercial fire alarm installer

Genesis LED EG4 Series appliances draw significantly less current than legacy Xenon strobes, which means more devices per NAC circuit, longer wire runs, and fewer booster power supplies on the job. LED and Xenon devices can be mixed on the same circuit, so retrofits don't require ripping out what's already working. The low-profile housing protrudes only about 1.5 inches from the mounting surface with no visible screws. UL 1971 listed.

Key features

  • Selectable 15, 30, 75, or 110 cd strobe output via slide switch, accessible without removing the device from the wall
  • Field-configurable speaker wattage for optimal coverage and circuit loading
  • Low-profile housing protrudes 1.5" from the mounting surface with no visible mounting screws
  • GP10 room side wiring plate included for pre-installation, pre-wiring, and diagnostics check before device install
  • Backwards compatible with legacy Xenon Genesis strobes on the same NAC circuit
  • Fits standard electrical boxes: 1-gang, 2-gang, 3.5" octagon, and 4" square
  • 12-18 AWG in-out screw terminals for quick field wiring

System requirements

Strobe operates on 16-33 VDC or 16-33 VFWR NAC circuits. Speaker requires a supervised amplifier signal circuit. Compatible with Kidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, and Intelligent and Conventional Control Panels for strobe synchronization.

Specifications

SKUKD-EG4SVRF
BrandKidde Commercial
Form factorWall-mount speaker/strobe, low profile (~1.5" protrusion)
Strobe outputSelectable 15, 30, 75, or 110 cd (clear lens)
Strobe operating voltage16-33 VDC, 16-33 VFWR
Strobe flash rate1 fps (approx.)
Synchronization20 Ω max. between any two devices
Sync sourcesKidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, Intelligent and Conventional Control Panels
Housing colorRed
Housing markingFIRE
Lens materialClear polycarbonate
Dimensions4.95 x 5.78 x 1.62 in (12.57 x 14.68 x 4.11 cm) (W x H x D)
Wire size12-18 AWG (0.75-2.50 mm²)
Compatible electrical boxes1-gang, 2-gang, 3.5" octagon, 4" square (min. 1-1/2" deep)
Mounting plateGP10 room side wiring plate (included)
Trim platesEG4TR (red), EG4TW (white) - optional
Operating temp32-122°F (0-50°C)
Operating humidity0-93% noncondensing
Storage temp-40-158°F (-40-70°C)
ComplianceUL 1971, FCC

Documents and resources

FAQs

Can I mix Genesis LED EG4 strobes with existing Xenon strobes on the same circuit?
Yes. EG4 LED devices are backwards compatible with legacy Xenon-based Genesis strobes. They can share the same NAC circuit and the same synchronization source, so you can upgrade incrementally without replacing every device on the loop.
What electrical boxes does the Genesis EG4 speaker/strobe fit?
Standard 1-gang, 2-gang, 3.5-inch octagon, and 4-inch square electrical boxes. Boxes must be at least 1-1/2 inches (3.81 cm) deep.
Can I change the strobe candela setting without removing the device?
Yes. The candela selector switch is accessible through a small window on the side of the device. Slide the switch to select 15, 30, 75, or 110 cd. The setting remains visible after the cover is closed.
What synchronization source does the EG4 require?
Compatible with Kidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, and Intelligent and Conventional Control Panels. Maximum 20 ohms wire resistance between any two devices on the synchronization loop.
Is the room side wiring plate included?
Yes. The GP10 room side wiring plate ships with every EG4 Series device. It allows pre-installation and pre-wiring before the appliance arrives on site, and includes a diagnostics check bar for verifying electrical continuity.
