  • Luminys | R3 Starter Series NVR, 8MP 8 Ch Mini 8-Port PoE, 1SATA, Analytics By Camera | R31-8PA

You save

Luminys | R3 Starter Series NVR, 8MP 8 Ch Mini 8-Port PoE, 1SATA, Analytics By Camera | R31-8PA

Luminys | R3 Starter Series NVR, 8MP 8 Ch Mini 8-Port PoE, 1SATA, Analytics By Camera | R31-8PA

No reviews yet Write a Review
SKU:
LM-R31-8PA

The R31-8PA puts 8-channel 4K recording into a mini enclosure with eight integrated PoE ports, so a small commercial install comes together without a separate switch or a rack-mount chassis. Single SATA bay supports up to 10TB, and analytics -- motion, VCA, face detection, and LPR -- process camera-side to keep recording bandwidth manageable at 80 Mbps.

Built for tight spaces, real commercial installs

The compact chassis fits a wiring closet shelf or small wall-mount enclosure without breaking the camera budget. ONVIF and RTSP interoperability means it accepts cameras from your existing line card, not just Luminys IPC. NDAA Section 889 compliant and FCC certified -- cleared for government, education, and public-sector jobs.

Key benefits

  • Eight built-in PoE ports (802.3 af/at, 72W budget): power cameras directly from the NVR -- no separate switch to mount or commission
  • Up to 8MP (4K) recording with H.265: captures fine detail and keeps file sizes in check on a single HDD
  • Camera-side analytics: intelligent motion detection and VCA on all 8 channels; face detection and LPR on 4 channels -- no server-side license required
  • ONVIF and RTSP compatible: works with cameras already in your kit, not just Luminys hardware
  • LumiCloud Lite included: remote access via LumiViewer app (iOS and Android) at no extra charge; upgrade to HD subscription when the site needs it
  • NDAA Section 889 compliant: eligible for federal and state government contracts

System requirements

One SATA HDD (up to 10TB, sold separately). Network uplink via single RJ-45 port (10/100 Mbps). Accepts any ONVIF-compatible IP camera or Luminys IPC. Display via HDMI (up to 4K) or VGA.

Brand:
Luminys
Form factor:
Mini (non-rack), desktop
Channels:
8
Recording resolution:
Up to 8MP (3840Ɨ2160); 6MP, 5MP, 4MP, 3MP, 1080p, 720p, D1, VGA, CIF
Compression:
H.265, H.264, H.264H, H.264B, MJPEG
Decoding capability:
2-ch @ 4K (8MP) @ 30fps; 8-ch @ 1080p @ 30fps
Recording bandwidth:
80 Mbps incoming; 60 Mbps outgoing
Video output:
HDMI (up to 4K / 3840Ɨ2160), VGA
Storage:
1x SATA, up to 10TB HDD (not included)
PoE ports:
8x RJ-45, IEEE 802.3 af/at; 72W total, 25.5W per port max
Network uplink:
1x RJ-45, 10/100 Mbps
Audio:
1x RCA input, 1x RCA output
USB:
2x USB 2.0 (1 front, 1 rear)
Analytics:
IMD 8-ch, VCA 8-ch, Face Detection 4-ch, LPR 4-ch (camera-side)
Remote access:
LumiCloud Lite (included); LumiViewer mobile app (iOS/Android)
Interoperability:
ONVIF, RTSP
Power input:
48V/53V DC via included AC adapter (120V AC input)
Power consumption:
Operating temp:
10Ā°F to 131Ā°F (-10Ā°C to 55Ā°C)
Operating humidity:
10% to 93%
Dimensions:
10.2" Ɨ 9.2" Ɨ 1.8" (260 Ɨ 233.2 Ɨ 43.7 mm)
Weight:
4.6 lb (2.1 kg) without HDD
Compliance:
NDAA Section 889, FCC
Does this NVR work with cameras from other brands?
Yes. The R31-8PA is ONVIF and RTSP compatible, so it works with cameras from most major IP camera manufacturers -- not just Luminys. Verify ONVIF conformance with your specific camera model before installation.
Do I need a separate PoE switch to power cameras?
No. The R31-8PA has 8 built-in PoE ports (IEEE 802.3 af/at) with a 72W total budget and up to 25.5W per port. Cameras connect directly to the NVR -- no external switch required for an 8-camera site.
What analytics does the R31-8PA support?
Analytics run camera-side, no server license required. IMD (8-ch), VCA (8-ch), Face Detection (4-ch), and LPR (4-ch). Smart Search filters footage by target class, channel, time, and event type.
How much HDD storage does this NVR support?
One internal SATA drive, up to 10TB (HDD not included). For longer retention or higher-resolution recording, Luminys also offers the R32-8PA with a 2-SATA configuration.
Is the R31-8PA NDAA compliant?
Yes. The R31-8PA is NDAA Section 889 compliant, making it eligible for federal, state, and local government contracts. FCC certified.
What remote access platform does this NVR use?
LumiCloud Lite is included. Access footage via LumiViewer desktop client or mobile app (iOS and Android). Premium LumiCloud HD subscriptions available when higher-bitrate remote streaming is needed.
