- Wireless technology Wi-Fi
Omada Pro AX3000 Wall-Plate Wi-Fi 6 Access Point with 3 Gigabit Ports and PoE Passthrough
SKU TPL-AP7650 Model AP7650
- AX3000 dual-band Wi-Fi 6 in a wall plate, with 120+ concurrent clients
- Gigabit uplink plus three Gigabit jacks, one with PoE out for a phone or IoT device
- Runs on 802.3af/at PoE from the closet; PoE passthrough needs 802.3at PoE+ input
- Managed by Omada Pro controllers with PPSK, 802.1X and zero-touch provisioning
- Fast shipping from four branches
- 30-day returns on unopened products
Product highlights
- ConnectivityAX3000 Wi-Fi 6
- Ports1 uplink + 3 Gigabit jacks
- PoE802.3af/at in, 1 port out
- MountWall plate, kit included
- CompatibilityOmada Pro controllers
The Omada Pro AP7650 puts AX3000 Wi-Fi 6 and three wired Gigabit jacks in a wall-plate form factor, so one cable run to a hotel room, dorm or office gives the room both strong Wi-Fi and wired ports for a TV, phone or desk. One downlink port passes PoE through to a powered device such as an IP phone.
Built for the hospitality and MDU installer
The AP7650 runs on 802.3af or 802.3at PoE from the closet switch and mounts on the wall with the included kit. Dual-band Wi-Fi 6 delivers up to 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz with OFDMA and 120+ concurrent clients. It is part of the Omada Pro line, so it is managed from the Omada Pro Cloud-Based Controller or Omada Pro Software Controller with zero-touch provisioning, multi-site management and WIDS/WIPS for large property portfolios.
Key features
- One drop, Wi-Fi plus wired: Gigabit uplink and three Gigabit downlink jacks at the wall
- PoE passthrough: one downlink port powers a PoE device when the AP is fed 802.3at PoE+
- AX3000 dual-band Wi-Fi 6: OFDMA, beamforming, band steering and airtime fairness
- Room-level security: PPSK, 802.1X, WPA3, client isolation and WIDS/WIPS through the controller
- Zero-touch provisioning with the Omada Pro Cloud-Based Controller, no tech needed on site to configure
- Wall-plate mounting kit included
System requirements
Requires an Omada Pro controller (the Omada Pro Cloud-Based Controller or Omada Pro Software Controller); Omada Pro devices are not managed by the standard Omada controllers. Power from an 802.3af/at PoE switch; PoE out on the downlink requires 802.3at PoE+ input.
Specifications
| SKU | TPL-AP7650 |
|---|---|
| Brand | TP-Link |
| Form factor | Wall-plate dual-band Wi-Fi 6 access point |
| Communication | Ethernet / IP |
| Power input | 802.3af/at PoE |
| Power consumption | 12.6 W max (802.3at, PoE out off) |
| Wi-Fi standard | Wi-Fi 6 |
| PoE | 802.3af PoE |
| PoE | 802.3at PoE+ |
| Port speed | Gigabit |
| Works with | Omada Pro |
| Ethernet ports | Uplink: 1 x Gigabit RJ45; downlink: 3 x Gigabit RJ45 |
| PoE output | 1 downlink port, requires 802.3at PoE+ input |
| Wireless standards | IEEE 802.11ax/ac/n/g/b/a |
| Wireless speed | Up to 2402 Mbps on 5 GHz, up to 574 Mbps on 2.4 GHz |
| Concurrent clients | 120+ |
| Antennas | Internal dual-band: 2 x 3 dBi (2.4 GHz), 2 x 5 dBi (5 GHz) |
| SSIDs | Up to 16 (8 per band) |
| Wireless security | WPA3, WPA2 and WPA Personal/Enterprise, 802.1X, PPSK, WIDS/WIPS, rogue AP detection, client isolation |
| Controller management | Omada Pro Cloud-Based Controller or Omada Pro Software Controller; Omada app |
| Communication notes | SNMP v1/v2c/v3, SSH, HTTP/HTTPS web management, local/remote syslog, management VLAN, RADIUS accounting |
| Mounting | Wall plate (kit included) |
| Dimensions | 5.6 x 3.4 x 1.7 in (143 x 86 x 42.6 mm) |
| Operating temp | 32°F to 104°F (0°C to 40°C) |
| Operating humidity | 10 to 90% RH, non-condensing |
| Compliance | FCC |
| Package contents | AP7650, mounting kit, installation guide |
