Genesis LED EGCS Series Ceiling Mount Speaker/Strobe, 15-115 cd Selectable, Red, Unmarked
Kidde Commercial

Genesis LED EGCS Series Ceiling Mount Speaker/Strobe, 15-115 cd Selectable, Red, Unmarked

SKU KD-EGCSVRN

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The Kidde Genesis LED EGCSVRN is a ceiling-mount speaker/strobe that combines audio and visual notification in a single low-profile appliance. Selectable 15, 30, 75, or 115 candela output and 25V/70V speaker operation give you one device that adapts to the job instead of stocking multiple SKUs.

Built for the commercial installer

The EGCS Series mounts to standard 2-gang or 4-inch square electrical boxes with a minimum 1-1/2 inch depth. The included room-side wiring plate (GRSW) keeps all wiring accessible from the finished side of the ceiling - no need to get above the drop tile to make connections. Candela and wattage settings are field-selectable without removing the device from the box; just slide the switches under the cover skin. UL and ULC listed for fire alarm notification appliance service.

Key features

  • Selectable candela output (15/30/75/115 cd): one SKU covers a range of coverage requirements per NFPA 72 spacing tables
  • Selectable speaker voltage and wattage: 25V or 70V operation at , , 1, or 2W - adapts to the existing NAC circuit design
  • Room-side wiring plate included: GRSW plate ships with every unit - wire from below the ceiling without accessing the plenum
  • Four LED strobe lenses: xenon-free design with synchronized flash capability when paired with Kidde CC Series signal modules
  • Low-profile ceiling mount: 6.8" diameter x 1.82" deep - sits tight to the ceiling on standard boxes
  • UL and ULC listed for fire alarm notification appliance service

System requirements

Requires a compatible fire alarm control panel or signal module for strobe synchronization. Synchronization sources include Kidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, and Intelligent and Conventional Control Panels. Maximum 20 wire resistance between any two synchronized devices.

Specifications

SKUKD-EGCSVRN
BrandKidde Commercial
Form factorCeiling-mount speaker/strobe, low profile
Light output15, 30, 75, or 115 cd (field-selectable)
Strobe operating voltage16 to 33 VDC, 16 to 33 VFWR
Speaker operating voltage25VRMS or 70VRMS (field-selectable)
Speaker wattage¼, ½, 1, or 2W (field-selectable)
Speaker frequency response400Hz - 4,000Hz
Sound output78-87 dBA reverberant (UL 1480), 77-86 dBA anechoic (CAN/ULC-S541)
Strobe flash rate1 fps (approx.)
Strobe current draw35 mA (VDC), 45 mA (VFWR) - all candela settings
Synchronization20 Ω max. between any two devices
Synchronization sourcesKidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, Intelligent and Conventional Control Panels
Wire size12 to 18 AWG (0.75 to 2.50 mm²)
Dimensions6.8 x 1.82 in (17.27 x 4.62 cm) Ø x D
Strobe-to-box center offset-1.70 in (-4.32 cm)
Compatible electrical boxes2-gang, 4-inch square (min. 1-1/2 in. deep)
Trim platesEGCTR (red), EGCTW (white) - 10.6 x 0.3 in.
Housing colorRed (RAL 3013)
Housing markingNone (unmarked)
Operating temp32 to 122°F (0 to 50°C)
Relative humidity0 to 93% noncondensing
Storage temp-40 to 158°F (-40 to 70°C)

Documents and resources

FAQs

Does this speaker/strobe work with both 25V and 70V systems?
Yes. The Genesis LED EGCS Series speakers support both 25VRMS and 70VRMS operation. The voltage is field-selectable via a switch under the cover.
What candela settings are available?
Four field-selectable settings: 15, 30, 75, or 115 candela. The setting is changed by sliding the candela switch under the cover skin - no need to remove the device from the electrical box.
What electrical boxes does this mount to?
Standard 2-gang or 4-inch square electrical boxes with a minimum depth of 1-1/2 inches (3.81 cm). Kidde recommends mounting at 81 inches AFF.
Is the room-side wiring plate included?
Yes. The GRSW room-side wiring plate ships with every EGCS Series appliance. It allows all wiring connections from the finished (room) side of the ceiling.
Can the strobe be synchronized with other notification devices?
Yes. Strobes synchronize at 1 fps when connected to compatible Kidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, or Intelligent and Conventional Control Panels. Maximum wire resistance between any two devices is 20 Ω.
What is the current draw for the strobe circuit?
35 mA on 16-33 VDC, 45 mA on 16-33 VFWR. Current draw is the same across all candela settings (15, 30, 75, 115 cd).
