Kidde | Genesis WG4 Outdoor Weatherproof Wall Strobe, Red, FIRE Marking, Field-Selectable Candela | CS405-7A-T

The Kidde Genesis WG4 outdoor weatherproof strobe puts visible fire notification on exterior walls and ceilings without compromising on output or reliability. UL 1638 listed for outdoor use and UL 1971 listed for indoor, it handles parking garages, loading docks, covered walkways, and other wet or harsh environments where standard indoor strobes fall short.

Built for the commercial installer

Rated from -40°F to 151°F with 0-95% humidity tolerance, the WG4 strobe handles extreme conditions that push indoor-only appliances past their limits. Four field-selectable candela settings let you dial in the right output per zone without stocking multiple SKUs. Candela selection stays visible through a sealed viewport on the front of the device - no need to open the cover to verify the setting after install.

Key features

• UL 1638 outdoor and UL 1971 indoor listed: one appliance covers both environments on a single NAC circuit
• Four selectable candela intensities: field-configurable standard output (15/29/70/87 cd indoor) without swapping hardware
• -40°F to 151°F operating range: rated for parking structures, loading docks, and exposed exteriors
• Genesis synchronization compatible: precision-timed flash sync with Genesis Signal Master or compatible auto-sync output modules
• Flexible mounting: wall or ceiling mount to Model 449 or 74347U outdoor-rated surface boxes, or standard 4" square by 1.5" deep boxes indoors
• Room-side wiring on 12-18 AWG: all connections accessible from the front - no reaching behind the box

System requirements

Requires a Model 449 (gray) or 74347U (red) outdoor-rated surface mount box for exterior or wet-area installations. For indoor dry locations, a standard 4-inch square by 1.5-inch deep electrical box works. Operates on 24 VDC or 24 VFWR nominal from any compatible FACP NAC circuit.
