Genesis LED G4 Wall Mount Mass Notification Speaker-Strobe, Green Lens, Alert, 25V/70V Selectable
Kidde Commercial

Genesis LED G4 Wall Mount Mass Notification Speaker-Strobe, Green Lens, Alert, 25V/70V Selectable

SKU KD-G4SVWA-G

New to SS&Si? Apply for a dealer account
Share
  • Fast shipping from four branches
  • 30-day returns on unopened products
Questions? Call us 866-364-0030The SS&Si dealer team

The Kidde G4SVWA-G is a Genesis LED G4 Series wall-mount speaker-strobe built for mass notification systems. It combines a selectable 25V/70V speaker with a green LED strobe and "ALERT" marking in a single compact appliance, covering voice paging and visual alerting from one device on a standard electrical box.

Built for the commercial installer

Speaker voltage (25VRMS or 70VRMS) and wattage (1/4W, 1/2W, 1W, or 2W) are both field-selectable without pulling the device off the wall. Voltage switches under the cover; wattage adjusts via a slide switch visible through the side window. The green LED strobe draws just 28 mA at 16-33 VDC, keeping NAC circuit loading low across large notification zones. Separate speaker and strobe circuit connections allow independent control from the FACP or mass notification system.

Key features

  • Combined speaker and strobe in one appliance - one backbox, one set of wire runs, faster installs
  • 25V/70V and 1/4-2W field-selectable without removing the device from the plate
  • Low-current LED strobe (28 mA VDC) keeps NAC loading manageable on large systems
  • Green lens with "ALERT" marking for mass notification applications
  • Standard 2-gang or 4-inch square box mounting - no proprietary backbox required
  • Separate speaker and strobe circuits for independent system control

System requirements

Requires a GRSW-10 room-side wiring plate (ordered separately). Mounts to any 2-gang or 4-inch square electrical box at least 1-1/2 inches deep. Optional trim plates (G4TR red, G4TW white) and surface mount boxes (EG4RSB red, EG4WSB white) available. Compatible with Kidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, and Intelligent and Conventional Control Panels for strobe synchronization. Wire with 12 to 18 AWG.

Specifications

SKUKD-G4SVWA-G
BrandKidde Commercial
Form factorWall-mount speaker-strobe, Genesis LED G4 Series
Speaker voltage25VRMS or 70VRMS (field-selectable)
Speaker wattage1/4W, 1/2W, 1W, or 2W (field-selectable)
Strobe operating voltage16 to 33 VDC, 16 to 33 VFWR
Strobe current draw28 mA (VDC), 36 mA (VFWR)
Light output65 cd (green lens)
Strobe flash rate1 fps
Speaker frequency response400Hz - 4,000Hz (UL rated); 100Hz - 11,000Hz (nominal)
Sound output78 dBA (1/4W), 81 dBA (1/2W), 84 dBA (1W), 87 dBA (2W) reverberant per UL 1480
Lens colorGreen
Housing colorWhite (RAL 9002)
MarkingALERT
Dimensions4.95 x 5.78 x 1.62 in (W x H x D)
Wire size12 to 18 AWG (0.75 to 2.50 mm²)
Mounting2-gang or 4-inch square electrical box, min 1-1/2 in deep
SynchronizationKidde CC Series Signal Modules, Booster/Aux Power Supplies, Intelligent and Conventional Panels; 20 Ω max between devices
Operating temp32 to 122°F (0 to 50°C)
Operating humidity0 to 93% noncondensing
Storage temp-40 to 158°F (-40 to 70°C)
ComplianceRoHS 2011/65/EU
Trim platesG4TR (red), G4TW (white) - optional
Wiring plateGRSW-10 (required, ordered separately)

Documents and resources

FAQs

Can I use this on both 25V and 70V speaker circuits?
Yes. Voltage is field-selectable via a switch under the cover. No need to stock separate 25V and 70V models. Wattage (1/4W, 1/2W, 1W, 2W) is also field-selectable via a slide switch on the side.
Does this require a separate wiring plate?
Yes. The GRSW-10 room-side wiring plate is required and ordered separately. The plate mounts to the electrical box first, then the appliance attaches to the plate.
What candela output does the green lens produce?
65 cd. Current draw is 28 mA (16-33 VDC) or 36 mA (16-33 VFWR).
Can the speaker and strobe run on separate circuits?
Yes. The device has independent speaker circuit in/out and strobe circuit in/out connections, allowing separate control from the FACP or mass notification system.
What electrical box does this mount to?
Standard 2-gang or 4-inch square box, minimum 1-1/2 inches deep. Surface mount boxes available: EG4RSB (red) or EG4WSB (white).
Is this compatible with Kidde intelligent fire alarm panels?
Yes. Synchronization sources include Kidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, and both Intelligent and Conventional Control Panels.
