The Kidde Genesis LED EG4AVRN is a wall-mount horn-strobe that delivers audible and visual notification from a single compact device. Field-selectable 15, 30, 75, or 110 candela output and high/low dB horn settings let you match the device to the space without swapping hardware or ordering a different SKU.
Built for the commercial installer
The EG4 Series runs on 16-33 VDC or 16-33 VFWR and draws as little as 40 mA at the lowest horn-strobe setting, keeping NAC circuit loading in check on longer runs. UL 464, UL 1638, ULC-S525, and ULC-S526 listed. Mounts on standard 1-gang, 2-gang, 3.5-inch octagon, or 4-inch square boxes with no adapter plates required. The included GP10 room-side wiring plate lets you terminate and test wiring before the device arrives on site.
Key features
- Field-selectable candela: 15, 30, 75, or 110 cd - adjust on-site without removing the device from the wall
- Dual sound output: high or low dB (up to 85 dBA reverberant), constant or TC3 temporal pattern
- Low current draw: 40-50 mA horn-strobe operation on DC, maximizing devices per NAC
- Room-side wiring plate included: GP10 ships with every unit for clean termination
- Synchronization ready: syncs strobes and horns across zones using Kidde CC Series signal modules or compatible control panels
- Red housing, no marking: clean appearance for applications where "FIRE" lettering isn't required by the AHJ
Compatibility
Works with Kidde CC Series Signal Modules, Booster and Auxiliary Power Supplies, and both Intelligent and Conventional Fire Alarm Control Panels. Mounts on standard electrical boxes (minimum 1-1/2 in. deep). Optional EG4TR trim plate available for finished installations.
What candela settings are available on the EG4AVRN?
Does this horn-strobe work with Kidde intelligent panels?
How much current does the EG4AVRN draw?
What electrical boxes does the EG4 Series fit?
Is the room-side wiring plate included?
Can the horn and strobe be synchronized across multiple devices?
